PARTS
OM 0408SB1174-A
43
SNOWBLOWER – SB1174
R
EF. DESCRIPTION QTY PART #
44 Coupling link #60
1
5RD654839
45 Spacer ring .656"ID x 1.760 x 1" ext. 1 5RD668093
46 Idler sprocket 60A12 1 5RD3300022
47 Spacer ring .656"ID x .807 x 1" ext. 1 5RD667777
48 Carriage bolt 5/16" NC x 1" gr.5 PTD 2 5RD0300003
49 Carriage bolt 1/2" NC x 1" lg gr.5 PTD 4 5RD0300022
50 Adjustable skid shoe 2 5RD669586
51 Nylon flat washer 7/16" hole 2 5RD658468
52 Flange bearing 1 1/4" hole, 4 holes 3 5RD4300001
53 Lockwasher 1/2" PTD 18 5RD1200006
54 Nut hex. 1/2" NC PTD 22 5RD0900006
55 Nylon flat washer 11/32" hole 4 5RD658467
56 Sprocket 60A32 1 5RD654167
57 Access plate 1 5RD669597
58 Bolt hex. 1/2" NC x 1 1/2" lg gr.5 PTD 12 5RD0100070
59 Bolt hex. 5/8" NC x 4 1/2" lg gr.5 PTD 1 5RD0100104
60 Flat washer 5/8" (11/16" dia. trou) 2 5RD1400008
61 Lockwasher 5/8" PTD 1 5RD1200007
62 Nut hex. 5/8" NC gr.5 PTD 1 5RD0900007
63 Rotation bushing 1 5RD662834
64 Bolt hex. 3/8" NC x 3/4" lg gr.5 PTD 4 5RD0100037
65 Drive shaft 1 5RD669720
66 Eyebolt 3/8" NC x 4" lg w/ nut 1 5RD0400027
67 Gearbox 1 5RD663485
