2-13
2.6 Filtration System Components (cont.)
ITEM PART # COMPONENT
106-9313 Filter Pan Assembly
1 823-7086 Filter Pan
2 220-4446 SanaGrid Filter Screen
3 810-3414 Ring, Wireform Holddown
4 824-1957 Crumb Basket
* 826-1392 O-ring (Pkg. of 5; used with Item 1)
5 823-6714 Lid, Filter Pan
6 106-5906 Wiring Harness Assembly, Filter Pump, 208/240V
* 106-5912SP Heater Strip Assembly, 18" 240V 25W
7 826-1756 Motor, 208V 50/60 Hz (Gasket, 816-0093, included.)
8 810-1067 Flexline, 5/8" OD x 8.5" long
9 810-1068 Flexline, 5/8" OD x 21.5" long
10 810-1668 Adaptor, Male 5/8" OD x ½"
11 813-0022 Nipple, ½" x Close NPT
12 813-0062 Elbow, ½" Black 90°
13 810-3346 Pump, Viking 4 GPM
106-9255 Oil Return Handle
14 810-3421 Rod, Rear Flush Oil Return
15 809-0601 Clip, Clevis, Rod End
16 220-5218 Bracket, Rod Retainer
17 108-0078 Bracket Stud Assembly
18 816-0220 Insulation, Switch
19 807-2103 Microswitch (Straight Lever)
20 810-0677 Grip, Drain Handle, Yellow Vinyl
21 809-0237 Nut, 4-40 Keps Hex with Extended Tooth
* Not illustrated.
