2-14
2.7 Frypot and Associated Parts
1
2
5
6
4
3
7
8
9
F
r
o
n
t
o
f
F
r
y
p
o
t
ITEM PART # COMPONENT
Frypot Assembly
1 823-6706 Frypot
2 807-0128 Bushing, Insulating, Heyco
3 220-4564 Handle, Oil Return
4 900-2935 Retainer Nut, Oil Return Valve
5 810-0278 Valve, ½" Ball
6 813-0165 Elbow Street, ½" x 2" NPT
7 813-0087 Nipple, ½" x 1.50"
8 813-0062
Elbow, ½" 90°
9 813-0298 Nipple, ½" x 2" NPT
* 826-2454
Hi-limit Thermostat, 425°F
* 106-5876SP Tilt Switch
* 807-0012 Tilt Relay
