4-30
ITEM PART # COMPONENT
1 Transformer (for use in BIH152 units)
807-1238 100/24VAC 50 Hz
807-0800 120/24VAC 50/60 Hz
2 807-0855 Transformer, 120/12VAC 50/60 Hz (for use in BIH152 units)
3 807-0012 Relay, 18 Amp 24VDC Coil
4 807-0273 Block, 16-Pin Terminal
5 807-1612 Clamp, ⅜-inch Strain Relief
6 807-0255 Jumper, Double
7 810-0045 Bushing, .875-inch Diameter
* 809-0362 Screw, 8-32 x 1-inch Hex Slotted Washer Head (for mounting Items 1-4)
8 900-5560 Shield, BIH152 Transformer
9 807-1683 Relay, 15 AMP 12VDC Coil
10 826-1363 Screw, 8-32 x ½-inch Slotted Truss Head (Pkg. of 25)
11 809-0050 Nut, 8-32 Hex
12 Transformer (for use in MH152 and BIH252/352/452/552 units)
807-2176 100-120/24/12VAC (used in U.S., Japanese, and Korean units) Dual Voltage
807-1999 208-240/24/12VAC (used in CE and most export units) Dual Voltage
13 809-0360 Screw, 8-32 x ⅜-inch Slotted Hex Washer Head
14 807-1973 Block, 4-Post Threaded Terminal (used in Non-CE units)
15 826-1389 Screw, ¼-20 x ¾-inch Hex Head (Pkg. of 10)
16 826-1362 Nut, ¼-20 Hex (Pkg. of 10)
* 809-0052 Nut, 10-24 Hex (for use on Item 14 and Item 36 terminal posts)
17 810-1163 Block, 3-Position Push-In Terminal (used in CE units)
18 826-1359 Screw, 4-40 x ¾-inch Slotted Round Head (Pkg. of 25)
19 826-1366 Nut, 4-40 Keps Hex (Pkg. of 10)
20 807-0070 Terminal, Lug
21 826-1363 Screw, 8-32 x ½-inch Slotted Truss Head (Pkg. of 25)
22 809-0247 Nut, 8-32 Keps Hex
23 900-2697 Box, MH152 Transformer
24 900-2708 Cover, MH152 Transformer Box Top
25 900-2703 Cover, MH152 Transformer Box Left
26 900-2709 Cover, MH152 Transformer Box Right
27 826-1374 Screw, #10 x ½-inch Self-Tapping Slotted Hex Washer Head (Pkg of 25)
28 900-5924 Box, BIH252/MH252 Transformer
29 900-5927 Cover, BIH252/MH252 Transformer Box Top
30 900-5928 Cover, BIH252/MH252 Transformer Box Left
31 900-5923 Cover, BIH252/MH252 Transformer Box Right
32 900-5925 Box, BIH352/MH352 Transformer Box
33 900-5929 Cover, BIH352/MH352 Transformer Box Top
34 900-5928 Cover, BIH352/MH352 Transformer Box Left
35 900-5930 Cover, BIH352/MH352 Transformer Box Right
36 807-2608 Block, 8-Post Threaded Terminal (used in Non-CE units)
37 810-1162 Block, 4-Position Push-In Terminal (used in CE units)
38 900-5926 Box, BIH452/MH452 Transformer
39 900-5931 Cover, BIH452/MH452 Transformer Box Top
40 900-5932 Cover, BIH452/MH452 Transformer Box Left
41 900-5930 Cover, BIH452/MH452 Transformer Box Right
* 807-0156 Connector, 9-Pin Plug
* Not illustrated.
