4-19
4.3.4 Service Frypot Kits, Insulation Kits, and Miscellaneous Service Parts
Service Frypot Kits
The fully assembled service frypot kits listed below contain all components illustrated on Pages
4-15 and 4-17 except the plenum, and the plenum gasket retainer. The kits also contain two
Ignitor Gaskets (816-0059). These service frypot kits are ready for installation.
• 106-1043SP – Full Vat (Manufactured Gas)
• 106-1049SP – Full Vat (Natural Gas (G20/G25)
• 106-1050SP – Full Vat (Propane/Butane (G30/G31))
• 106-1066SP – Dual Vat (Manufactured Gas)
• 106-1079SP – Dual Vat (Natural Gas (G20/G25))
• 106-1080SP – Dual Vat (Propane/Butane Gas (G30/G31))
Insulation Kits, Complete
The insulation kits listed below contain all insulation illustrated on Pages 4-15 and 4-17,
respectively. The kits also contain two Ignitor Gaskets (816-0059), two Sight Glasses (814-
0048SP), two Plenum Gaskets (816-0057), one Upper Frypot Insulation Retainer (900-1515),
and all spacers, screws, nuts, and washers required for installing the insulation.
• 826-0929 – Full Vat
• 826-0930 – Dual Vat
Insulation Kits, Burner
• 826-0931 – Full Vat
This kit includes the components listed. Item numbers refer to illustration on Page 4-15.
816-0577 – Insulation, Burner (Item 25) (3 each)
812-0457 – Insulation, Full Vat Inner Combustion Chamber (Item 18) (1)
812-0355 – Insulation, Full Vat Rear Combustion Chamber (Item 30) (1)
816-0057 – Gasket, Plenum (Item 4) (2 each)
• 826-0932 – Dual Vat
This kit includes the components listed. Item numbers refer to illustration on Page 4-17.
816-0577 – Insulation, Burner (Item 23)
812-0458 – Insulation, Dual Vat Inner Combustion Chamber (Item 17) (1)
812-0354 – Insulation, Dual Vat Rear Combustion Chamber (Item 29) (1)
816-0057 – Gasket, Plenum (Item 4)
Miscellaneous Frypot Service Parts
• 210-0681 – Probe Guard
• 806-6142SP – Riser Assembly, Flue (replaces upper section of Flue Assemblies 806-5859SP
and 106-1018SP.)
• 900-2298 – Shutter, BIH152 Plenum
