4-18
ITEM PART # COMPONENT
1 Plenum
823-0970SP Standard Dual Vat
823-1049 For use on units with Air Switch. HE Dual Vat European
823-2181 For use on JBIH152 models only.
2 826-1372 Nut, ¼-20 Hex (Pkg of 10)
3 826-1383 Washer, ¼-inch x ¾-inch Flat (Pkg. of 5)
4 816-0057 Gasket, Plenum
5 900-1049 Retainer, Plenum Gasket
6 826-1371 Screw, #8 x ½-inch Hex Head (Pkg of 25)
7 826-1368 Nut, ¼-20 Serrated Flange (Pkg. of 10)
8 810-0500 Spacer, ¼-inch x 15/16-inch
9 823-0968SP Retainer, Dual Vat Outer Combustion Chamber Insulation
10 816-0558 Insulation, Dual Vat Combustion Chamber Outer Lower
11 826-1340 Spacer, ¼-inch x 1 3/16-inch (Pkg of 10)
12 900-1031 Retainer, Sight Glass
13 812-0356 Gasket, Sight Glass
14 814-0048SP Sight Glass
15 823-0983SP Retainer, Dual Vat Inner Combustion Chamber Insulation
16 812-0458 Insulation, Dual Vat Inner Combustion Chamber
17 930-3628 Retainer, Dual Vat Frypot Outer Front Insulation
18 816-0559 Insulation, Dual Vat Frypot Outer Front
19 824-0865 Seal, Dual Vat Frypot Left
20 824-0866 Seal, Dual Vat Frypot Right
21 812-0404 Insulation, Frypot Seal
22 Kit, Burner Replacement (for use on either side; includes Item 23)
826-1072 Natural and Propane Gas
826-1073 Manufactured Gas
23 816-0577 Insulation, Burner
24 823-2823 Rail, Dual Vat Right Burner Side W/A
25 823-2822 Rail, Dual Vat Left Burner Side W/A
26 812-1029 Insulation, Frypot Side
27 900-4452 Retainer, Frypot Side Insulation
28 809-0362 Screw, #8 x 1-inch Hex Washer Head
29 812-0354 Insulation, Dual Vat Rear Combustion Chamber
30 200-0941 Back, Dual Vat Combustion Chamber
31 900-0914 Retainer, Dual Vat Combustion Chamber Back
32 812-0688 Insulation, Dual Vat Gas Collector
33 930-0818 Bracket, Flue to Frypot Mounting
34 810-0406 Spacer, ¼-inch x 1 7/16-inch
35 106-1018SP Flue Assembly, Dual Vat
36 812-0993 Insulation, Frypot Upper
37 900-1515 Retainer, Frypot Upper Insulation
38 900-0857 Bracket, BIH52 Frypot Mounting
39 900-1401 Bracket, MH52 Frypot Mounting
40 812-0706 Insulation, Burner Rail
41 900-4253 Strip, Fluecap Retainer
42 824-0541 Riser, DV Pot Divider W/A
* 910-2474 Pot-to-Pot Gap Clip
* 813-0156 Plug, ½-inch NPT BM (for blocking off unneeded ports in service frypot)
* 813-0336 Plug, ½-inch NPT SS (for blocking off unneeded ports in service frypot)
* Not illustrated.
