4-40
ITEM PART # COMPONENT
1 826-1264 Pump, 4 GPM (15 LPM) (comes with Gasket 816-0093)
2 Motor and Gasket Kit, Multi-Voltage
826-1712 100-120VAC (replaces earlier kits 826-1260, -1263, and -1268)
826-1713 200-250VAC (replaces earlier kits 826-1262, -1266, -1269, and -1270)
3 807-2484 Valve, Solenoid Vent
4 810-1404 Flexline, Oil Return (pump to rear manifold)
5 810-1373 Flexline, Pump Bypass
6 806-9437SP
Flexline, 15½-inch (39.5cm) Oil Return (See NOTE below)
7 813-0165 Elbow, ½-inch x 90º Street
8 813-0530 Tee, ½-inch x ¼-inch x ½-inch Reducing
9 813-0537 Nipple, ¼-inch x 2-inch
10 813-0543 Elbow, ¼-inch x 90º Street
11 813-0265 Nipple, ½-inch x 2½-inch
12 813-0460 Nipple, ½-inch x 3-inch
13 813-0304 Bushing, ½-inch to ¼-inch Reducing
14 813-0331 Elbow, ½-inch 3-way
15 810-1159 Flexline, 5-inch Oil Return
16 Hose, Heated Oil Return
810-0945 100-120VAC
810-1037 208-250VAC
17 900-1958 Support, Oil Return
18 810-1003 Valve, 180º 3-way Ball
19 813-0022 Nipple, ½-inch x Close
20 813-0062 Elbow, ½-inch x 90º
21 813-0098 Nipple, ½-inch x 6½-inch
22 813-0087 Nipple, ½-inch x 1½-inch
23 900-5543 Mount, Motor
24 826-1389 Screw, ¼-20 x ¾-inch Hex Head (Pkg. of 10)
25 809-0191 Washer, ¼-inch Lock
26 826-1362 Nut, ¼-20 Hex (Pkg. of 10)
27 809-0514 Capscrew 5/16”x 18 NC
28 809-0194 Washer, Flat 5/16 ZP
* 806-6728SP Wiring Assembly, Pump Motor to Filter Box
* 816-0093 Gasket, Pump Motor
* Thermal Switch
807-1600 Baldor Motor, 120VAC
807-1601 Baldor Motor, 240VAC
807-1598 Magnatek Motor, 120VAC
807-1599 Magnatek Motor, 240VAC
* 807-1420 Heater Tape 120V 25w 36” (Assy. 806-9245SP)
* 807-1472 Heater Tape 120V 40w 56” (Assy. 806-8004SP)
* 807-2304 Heater Tape 120V 100w 72” (Assy, 806-7755SP)
* 811-0746 Aluminum Tape – 50 yard roll
* 811-0861 Foam Insulation – by the foot
* Not illustrated.
NOTE: Item 6 consists of 13-inch Flexline 810-1057 and two ⅞-inch to ½-inch Male Adapters 810-1668,
which may be ordered as separate items.
