4-42
ITEM PART # COMPONENT
1 Pan Assembly, Filter (has screen alignment pins in pan bottom)
806-6423SP Standard
806-7377SP For use on Japanese/Far East (JBIH52) units.
2† 806-5618SP Pan Assembly, Filter (has no screen alignment pins in pan bottom) (Paper
pans used in Japan)
3 Cover, Filter Pan
823-2027 For use with 806-6423SP and 806-5618SP assemblies.
823-2321 For use with 806-7377SP units (has lower splash guard than 823-2027)
4 810-1405 Ring, Hold Down (for use with 806-6423SP and 806-7377SP assemblies)
5 810-1408 Ring, Hold Down (for use with 806-5618SP assembly)
6 900-8818 Screen, Sana Grid (9 x 17-inch/23 x 43cm, has alignment holes)
7 900-8819 Screen, Sana Grid (12 x 19.5-inch/30.5 x 49.5cm, has no holes)
8 823-2234SP Pan, Filter (has screen alignment pins in pan bottom)
9† 823-1979SP Pan, Filter (has no screen alignment pins in pan bottom)
10 809-0422 Screw, 10-32 x 7/16-inch Slotted Truss Head
826-1490 Kit, Filter Pan Check Valve Service (consists of Items 11 through 16)
11 810-1387 Retainer, Check Valve
12 900-5448 Strainer, Check Valve
13 810-0946 Spring, Check Valve
14 810-0948 Ball, Check Valve
15 810-1388 Tube, Check Valve
16 816-0597 O-Ring, Check Valve
17 824-0430 Screen, Crumb (used with 806-5618SP, 806-6423SP, and 806-7377SP)
18 823-2586 Cover, Filter Pan (for use with 823-2575SP)
19 823-2574 Ring, Hold Down (for use in 823-2575SP)
20 900-8829 Screen, San Grid (10 x 9-inch/23 x 25cm, for use in 823-2575SP) Baby FP
21 823-2575SP Pan, Filter (for use in BIH152 units)
22 823-2578 Bracket, BIH152 Oil Return
23 810-0697 Disconnect, Male
24 826-1392 O-Ring, BIH152 Oil Return (Pkg of 5)
25 809-0028 Nut, Wld 10-32 Sngl Wng
* 806-8550SP Inner Pan w/ ck valve and O-rings
† Used on some early-production Japanese/Far East (JBIH52) units only.
* Not illustrated.
