ITEM PART # COMPONENT
1 823-0969 Plenum (NOTE: use 823-1048 on units equipped with Air Switch)
2 826-1372 Nut, ¼-20 Hex (Pkg of 10)
3 826-1383 Washer, ¼-inch x ¾-inch Flat (Pkg. of 5)
4 816-0057 Gasket, Plenum
5 900-1049 Retainer, Plenum Gasket
6 826-1371 Screw, #8 x ½-inch Hex Head (Pkg of 25)
7 826-1368 Nut, ¼-20 Serrated Flange (Pkg. of 10)
8 810-0500 Spacer, ¼-inch x 15/16-inch
9 823-11691SP Retainer, Full Vat Left Outer Combustion Chamber Insulation
10 823-1169SP Retainer, Full Vat Right Outer Combustion Chamber Insulation
11 816-0561 Insulation, Full Vat Combustion Chamber Outer
12 826-1340 Spacer, ¼-inch x 1 3/16-inch (Pkg of 10)
13 900-1031 Retainer, Sight Glass
14 812-0356 Gasket, Sight Glass
15 814-0048SP Sight Glass
16 200-0935 Retainer, Full Vat Left Inner Combustion Chamber Insulation
17 200-0934 Retainer, Full Vat Right Inner Combustion Chamber Insulation
18 812-0457 Insulation, Full Vat Inner Combustion Chamber
19 200-2227 Retainer, Full Vat Frypot Outer Front Insulation
20 816-0560 Insulation, Full Vat Frypot Outer Front
21 824-0863 Seal, Full Vat Frypot Left
22 824-0864 Seal, Full Vat Frypot Right
23 812-0404 Insulation, Frypot Seal
24 Kit, Burner Replacement (for use on either side; includes Item 25)
826-1072 Natural and Propane Gas
826-1073 Manufactured Gas
25 816-0577 Insulation, Burner
26 823-3142 Rail, Full Vat Right Burner
27 823-1777 Rail, Full Vat Left Burner
28 812-1029 Insulation, Frypot Side
29 900-4452 Retainer, Frypot Side Insulation
30 812-0355 Insulation, Full Vat Rear Combustion Chamber
31 200-0936 Back, Left Full Vat Combustion Chamber
32 200-0937 Back, Right Full Vat Combustion Chamber
33 900-1221 Retainer, Full Vat Combustion Chamber Back
34 810-0406 Spacer, ¼-inch x 1 7/16-inch
35 930-0818 Bracket, Flue to Frypot Mounting
36 806-5859SP Flue Assembly, Full Vat
37 812-0993 Insulation, Frypot Upper
38 900-1515 Retainer, Frypot Upper Insulation
39 900-0857 Bracket, BIH52 Frypot Mounting
40 900-1401 Bracket, MH52 Frypot Mounting
41 809-0362 Screw, #8 x 1-inch Hex Washer Head
42 812-0706 Insulation, Burner Rail
43 900-4253 Strip, Fluecap Retainer
* 910-2474 Pot-to-Pot Gap Clip
* 813-0156 Plug, ½-inch NPT (for blocking off unneeded ports in service frypot)
* 813-0336 Plug, ½-inch NPT SS (for blocking off unneeded ports in service frypot)
* Not illustrated.
