4-22
NOTE: The drawings on the preceding page illustrate typical gas manifold configurations. Specific
configurations vary depending upon the number and types of fryers in a battery. The purpose of the
drawings is to illustrate all individual components that may be found in any given configuration.
Determination of which component to use in a particular application should be based upon careful
inspection of the existing components, including taking measurements when appropriate.
ITEM PART # COMPONENT
1 813-0087 Nipple, ½-inch NPT x 1½-inch (3.8 cm)
2 813-0003 Tee, ½-inch NPT
3 813-0156 Plug, ½-inch NPT Pipe
4 813-0173 Union, ½-inch NPT
5 813-0497 Nipple, ½-inch NPT x 12½-inch (31.8 cm)
6 813-0062 Elbow, ½-inch NPT x 90º
7 813-0320 Nipple, ½-inch NPT x 8-inch (20.3 cm)
8 813-0022 Nipple, ½-inch NPT x Close
9 813-0460 Nipple, ½-inch NPT x 3-inch (7.6 cm)
10 813-0031 Bushing, ¾-inch NPT to ½-inch Reducer
11 823-2260 Bracket, ¾-inch NPT Gas Manifold Mounting
12 813-0157 Plug, ¾-inch NPT Pipe
13 813-0168 Elbow, ¾-inch NPT x 90º Street
14 813-0110 Nipple, ¾-inch NPT x 1½-inch (3.8 cm)
15 813-0066 Elbow, ¾-inch NPT x 90º
16 813-0478 Nipple, ¾-inch NPT x 12½-inch (31.8 cm)
17 813-0271 Tee, ¾-inch NPT x ½-inch Branch
18 813-0386 Nipple, ¾-inch NPT x 12-inch (30.5 cm)
19 813-0387 Tee, ¾-inch NPT
20 813-0109 Nipple, ¾-inch NPT x Close
21 813-0479 Nipple, ¾-inch NPT x 11-inch (27.9 cm)
22 813-0068 Elbow, ¾-inch NPT x ½-inch NPT x 90º
23 813-0281 Nipple, ½-inch NPT x 5-inch (12.7 cm)
24 813-0515 Nipple, ½-inch NPT x 12-inch (30.5 cm)
24a 813-0360 Nipple, ½-inch x 14-inch (in CE BIH352-6 Natural Gas (G20/G25) units only)
25 813-0253 Nipple, ½-inch NPT x 10-inch (25.4 cm)
26 813-0265 Nipple, ½-inch NPT x 2½-inch (6.4 cm)
27 813-0112 Nipple, ¾-inch NPT x 2-inch (5.1 cm)
28 813-0476 Nipple, ¾-inch NPT x 14-inch (35.6 cm)
29 813-0096 Nipple, ½-inch NPT x 6-inch (15.2 cm)
30 900-0944 Plate, 1-inch NPT Gas Manifold Mounting
31 813-0202 Elbow, 1-inch NPT x 90º
32 813-0314 Tee, 1-inch NPT
33 813-0318 Nipple, 1-inch NPT x 3-inch (7.6 cm)
34 813-0138 Nipple, 1-inch NPT x Close
35 813-0371 Nipple, 1-inch NPT x 2-inch (5.1 cm)
36 809-0347 Nut, 1-inch NPT Retainer
37 810-0661 Manifold, 1-piece H252 Gas
38 810-0660 Manifold, 1-piece H352 Gas
39 813-0469 Cap, ½-inch NPT Pipe (closes off unused port in full vat configurations)
