Frymaster BIH52 Series - Page 95

4-24
ITEM PART # COMPONENT
1 Gas Valve, Non-CE Kit
826-1122 Natural Gas (G20/G25)
826-1123 Propane (LP) Gas (G30/G31)
2 810-0691 Vent Tube (used with Item 1)
826-1576 CE Gas Valve Kit (includes items 3 and 4)
3 810-1715 Gas Valve, Universal CE (G20/G25/G30/G31)
4 810-1041 Accessory Kit (2 straight and 2 elbow flanges, screws, O-rings, LP gas
spring)
5 806-9678 Plug Assembly, CE Gas Valve (used with Item 3)
6 807-1229 Gas Valve, Manufactured Gas
7 810-1176 Tap, ⅛-inch NPT Pressure
8 813-0411 Plug, ⅛-inch NPT Allen-head Pipe
9 813-0304 Bushing, ½-inch to ¼-inch NPT Reducer
10 810-1006 Bushing, ¼-inch to ⅛-inch NPT Reducer
11 813-0004 Elbow, 90º x ⅛-inch NPT
12 813-0354 Elbow, 90º x ⅛-inch NPT x ⅛-inch Tube (Brass)
13 813-0302 Elbow, 90º x ⅜-inch Tube x ¼-inch Male NPT (Brass)
14 813-0502 Elbow, 90º Street x ¼-inch (Brass)
15 813-0340 Connector, ⅛-inch Tube to ⅛-inch Male NPT (Brass)
* 810-0502 Connector, ⅛-inch Tube to ⅛-inch Male NPT (Brass) (with Item 6 only)
16 810-1025 Connector, ⅜-inch Tube to ¼-inch Male NPT (Brass)
17 813-0507 Coupling, ¼-inch NPT (Brass)
18 813-0378 Cross Fitting, ½-inch Female NPT (Brass)
19 810-1026 Tee, ¼-inch NPT Street (Brass)
20 813-0495 Tee, ¼-inch Male NPT Branch (Brass)
21 813-0377 Tee, ⅛-inch Female NPT (Brass)
22 813-0016 Nipple, ⅛-inch NPT Close
23 813-0315 Nipple, ⅛-inch NPT x 1½-inch (4.8 cm)
24 813-0405 Nipple, ⅛-inch NPT x 2-inch (5.1 cm)
25 813-0471 Nipple, ¼-inch NPT x 1½-inch (4.8 cm)
26 900-3739 Gas Tube (Left), H52 FV Manufactured Gas (pre-formed)
27 810-0503 Compression Nut (Ferrule), ½-inch Manufactured Gas Tube
28 900-3737 Gas Tube (Right), H52 FV Manufactured Gas (pre-formed)
* 900-3735 Gas Tube (Left and Right), H52 DV Manufactured Gas (pre-formed)
29 Flexible Stainless Steel Gasline (Flexline), ⅜-inch OD
810-1353 9-inch (22.9 cm) Kit 826-1530 includes 2 of #30
810-1354 12-inch (30.5 cm) Kit 826-1531 includes 2 of #30
810-1355 15-inch (38.1 cm) Kit 826-1532 includes 2 of #30
30 810-0494 Compression Nut (Ferrule), ⅜-inch Flexible Gas Line
* Enrichment Tube
811-0752 5½-inch (14 cm)
811-0756 8½-inch (21.6 cm) Brass Comp. Fitting 810-0502 for ignitor end
811-0800 12½-inch (31.8 cm) Brass Comp. Fitting 810-0340 for gas valve end
812-0742 18-inch (45.7 cm)
* Not illustrated.
