FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-11
2.4.2 SR and ESG35T Series, SM35G, SM40G and SM50G Systems (cont.)
ITEM PART # COMPONENT
1 121882 Frypot- S/S (After 6/98)-SR38G (use 12202-2 for Japan/Singapore
)obsolete
* 8261865 Frypot- S/S- SR42G (Began using 1” drain Mar. 2003)
* 8263302 Frypot- S/S- ESG35T
* 8261871 Frypot- S/S- SR52G, SM50G
* 8261867 Frypot- S/S- SM35G, SM40G
2 2105185 Diffuser, Burner Tube- SR38G, SM35G, SM40G
* 2302592 Diffuser, Burner Tube- SR42G
* 2600734 Diffuser, Burner Tube- ESG35T
* 2105175 Diffuser, Burner Tube- SM50G
* 2105216 Diffuser, Burner Tube- SR52G
* 2400666 Shutter, Single Burner- ESG35T Large Shutter
* 2208734 Shutter, Single Burner- ESG35T Small Shutter
3 8102150 Burner, Right- SR52G, SM50G
* 8102039 Burner, Right- SR38G, SR42G, SM35G, SM40G
4 8102149 Burner, Center- SR52G, SM50G
* 8102038 Burner, Center- SR38G, SR42G, SM35G, SM40G
* 8103356 Burner, Universal- ESG35T
5 8102151 Burner, Left- SR52G, SM50G
* 8102037 Burner, Left- SR38G, SR42G, SM35G, SM40G
* 2001329 Bracket, Burner Mounting- SR52G, SM50G
* 8090459 Bolts, Burner
5
/
16
" – 18x ¾" Hex Head Washer
* 8233600 Support Assy, Burner- SM35G, SM40G (Inc Burner Mtng Brkt & Heat Shld)
* 2001132 Shield, Burner Heat- SR42G not used after 12/10/04
* 2001330 Shield, Burner Heat- SR52G, SM50 and 200-1331
6 2001615 Bracket, Manifold Mounting- SR52G, SM50G
* 2001311 Bracket, Manifold Mounting- SR38G, SR42G
* 2400665 Bracket, Manifold Mounting- ESG35T
7 8090428 Bolt, ¼" -20 x ½" Hex Head
8 8090823 Nut, Nylock- ¼" -20
9 8130705 Plug, Brass- ⅛" Square Head
10 Orifice- Domestic/International
* 8102048 Orifice, Natural- #39 (2.53 mm)- SR52G, SM50G,
* 8102132 Orifice, Natural- #37 (2.64 mm)- SR38G
* 8102040 Orifice, Natural- #35 (2.80 mm)- SR42G, SM35G, SM40G
* 8103097 Orifice, Natural- #35 (2.80 mm) .125-⅛ NPT- SR42G 4/07-11/13
* 8103360 Orifice, Natural- #35 (2.80 mm) ⅛ NPT- SR42G after 11/13
* 8104389 Orifice, Natural- #44 (2.18 mm) ⅛ NPT – ESG35T (0-1999 Ft, 0-609 M)
* 8104451 Orifice, NG- #45 (2.08 mm) ⅛ NPT–ESG35T(2000-3999 Ft, 610-1219M)
* 8104452 Orifice, Natural- #46 (2.06 mm) ⅛ NPT – ESG35T (>4000 Ft, >1219 M)
* 8102497 Orifice, LP- #55 (1.32 mm)- SR52G, SR62G, SM20G, SM50G
* 8104456 Orifice, LP- (1.35 mm) ⅛ NPT-ESG35T (2000-3999 Ft, 610-1219 M)
* 8103529 Orifice, LP- #54 (1.40 mm) ⅛ NPT - ESG35T (0-1999 Ft, 0-609 M)
* 8102059 Orifice, LP- #53 (1.51 mm)- SR52G, SM50G,
* 8103102 Orifice, LP- #53 (1.51 mm) .125-⅛ NPT - SR42 after 4/07
* 8102063 Orifice, LP- #52 (1.61 mm)- SR38G
* 8102064 Orifice, LP- #51 (1.70 mm)- SR42G, SM35G, SM40G
* 8103099 Orifice, LP- #51 (1.70 mm), .125-⅛ NPT - SR42G 4/07-11/13
* 8103361 Orifice, LP- #51 (1.70 mm), ⅛ NPT - SR42G after 11/13
* 8102400 Orifice, LP- #16 (.016)- Pilot SR52
* Orifice- CE Only
* 8102060 Orifice, G20-G25- (2.40 mm)- All Millivolt Fryers in This Section
* 8103101 Orifice, G20-G25- (2.40 mm) .125-⅛ NPT - SR42 built after 4/07
* Not Illustrated
