Frymaster Dean Super Runner Series - Page 34

FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-12
2.4.2 SR and ESG35T Series, SM35G, SM40G and SM50G Systems (cont.)
ITEM PART # COMPONENT
* 8102059 Orifice, G31- (1.51 mm)- All Millivolt Fryers in This Section
* 8103102 Orifice, G31- (1.51 mm) .125-⅛ NPT- SR42 built after 4/07
11 8233618 Manifold, Gas- SR52G, SM50G
* 8102034 Manifold, Gas- SR38G, SR42G
* 8103006 Manifold, Gas- SR42G after 4/07, ESG35T
* 8233619 Manifold, Gas- SM35G, SM40G
Gas Valve and Related Plumbing- SM50G – Plumbing Will Vary From Model to
Model- Use the Following Parts As A Reference When Obtaining Parts For Systems
in This Section Other Than SM50G
12 8130165 Elbow, Stree
t
- ½" NPT 90° BM
13 8102036 Valve, Gas- Natural, Hone
y
well- Domestic/International ½” in x ¾” out
* 8071603 Valve, Gas- Natural, Hone
y
well- ½” in x ½” out Started usin
g
Feb. 2003
* 8073648 Valve, Gas- Natural, Hone
y
well- ¾” in x ¾” out Started usin
g
Feb. 2003 Expor
t
* 8073645 Valve, Gas- Natural, Robertshaw- ½” in x ¾” out
* 8073549 Valve, Gas- LP, Hone
y
well- Domestic/International
* 8071604 Valve, Gas- LP, Hone
y
well- ½” in x ½” out Started usin
g
Feb. 2003
* 8073553 Valve, Gas- LP, Hone
y
well- ¾” in x ¾” out
* 8101155 CE Adaptor Kit, Hone
y
well Valve
* 8072122 Valve, Gas- Natural, Hone
y
well- CE Onl
y
* 8072121 Valve, Gas- LP, Hone
y
well- CE Onl
y
* 8074137 Valve, Gas- Natural, Hone
y
well-Australia
* 8074138 Valve, Gas- LP, Hone
y
well- Australia
* 8071846 Valve, Kit
–
Natural to Propane Conversion
14 8130418 Nipple, ½” NPT x 17" BM- SM50G
* 8130670 Nipple, ½” NPT x 19" BM
(
Measure To Confirm Len
g
th
)
* 8130585 Nipple, ½” NPT x 20-½" BM
(
Measure To Confirm Len
g
th
)
* 8130737 Nipple, ½” NPT x 21" BM
(
Measure To Confirm Len
g
th
)
15 8130174 Union- ¾" NPT BM
16 8130254 Nipple, ¾” NPT x 3" BM- SM50G
17 8130066 Elbow- ¾” NPT 90° BM
18 8130112 Nipple, ¾” NPT x 2" BM- SM50G
19 8090805 Bolt, ¼”-20 x ½" Hex Head
20 8102043 Clamp, Pipe- ½"
* 2001450 Bracket, Gas-Suppl
y
Clamp Support
(
UFF-Equipped S
y
stems
)
21 8130031 Bushin
g
, ¾” NPT x ½” NPT BM
22 8100703 Gas Line, Pilot Suppl
y
- ¼” x 20”
(
For CE use 8101172 23” or 8102602 17-½"
)
23 8102033 Thermopile- Non-CE
* 8073565 Thermopile- CE Onl
y
(
Thermocouple 810-1152
)
24 8102032 Burner, Pilot- Natural
(
Use 1060692SP for Assembl
y
. Includes item 22, 23 and 24)
* 8102155 Burner, Pilot- LP
25 1061742SP Flue Assembl
y
- SR52G, SM50G
* 2002872 Shield, Flue Heat- SR52G, SM50G
* 2001343 Front, Flue Box- SR52G, SM50G
* 2001350 Rear, Flue Box- SR52G, SM50G
* 12203 Flue Assembl
y
- SR38G
* 120363 Shield, Flue Heat- SR38G obsolete
* 120362 Front, Flue Box- SR38G obsolete
* 120361 Rear, Flue Box- SR38G obsolete
* 1060696SP Flue Assembl
y
- SR42G
* 2001304 Front, Flue Box- SR42G
* 2001303 Rear, Flue Box- SR42G
* Not Illustrated
