FRYMASTER DEAN MILLIVOLT GAS FRYERS
CHAPTER 2: PARTS LIST
2-21
2.6.1 Oil Return Manifold Components; Fryers with 1½” Drains (cont.)
ITEM PART # COMPONENT
13 8130673 Nipple, ½” x 8-½" NPT BM
14 8102125 Oil Return Valve, ⅜"
* 8100051 Coupling, ½” NPT x 1-
/
16
” to adapt return hose to valve
* 2001143 Retainer, Oil Return Valve Nut
* 8090877 Nut, Oil Return Valve
15 8130006 Bushing, Hex- ½” x ⅜" NPT BM
16 8130625 Nipple, ⅜" x Close NPT BM
17 8130165 Elbow, Street- ½” x ½" NPT 90° BM
18 8130634 Elbow, ½” x ⅜" NPT 90° BM
19 8130062 Elbow, ½" NPT 90° BM
* 1062568SP Wash Down Hose and Nozzle Assembly
* Not Illustrated
