LOV
™
Technical Reference
44
J7 From RTI Box
1 From RTI transformer 24VAC Black
2 Common White
3
4 To Waste Solenoid - 3 Way 24VAC Brown
5
6 RTI JIB Valve Fill Solenoid 24VAC Green
7
Ground - Fill Solenoid
8
From RTI “Waste Tank Full
Sensor” Test Pins 1 to 8
0VDC – Full
5VDC – Not Full
Red
MIB (Manual Interface Board) Pin Positions and Harnesses (continued)
