LOV
™
Technical Reference
7
1-8 — Numbers corresponding to the vats.
A — Auto mode, auto fi ltration enabled.
C — Closed valve, display alternates between C and
vat number. LED blinks.
d — Drain issue; display alternates between d and vat
number.
E — Actuator circuit not sensing actuator; display
alternates between E and vat number.
(Ensure actuator is plugged in and in home position.)
F — Incomplete fi ltration; F alternates with n when
the MIB doesn’t receive a complete fi ltration response
from an AIF.
L —Loading; loading fryer confi guration. Shown
during initial startup, rare otherwise.
n — Network error; n alternates with r, indicating
a time-out on reset; n alternates with F, indicating
an incomplete fi ltration response (see F above); n
alternating with a vat number and a drain or return LED
blinking; time-out error opening or closing a valve.
O — Open valve; O alternates with vat number and
blinking LED.
P — Pan switch; fi lter pan is not in place or not
sensed. Auto Filtration disabled.
U — Fry battery not confi gured; the MIB board is
looking for a message from an M2007, allowing it to
initialize the battery.
r - Reset; r alternating with a vat number indicates
that the MIB board is resetting. If r is displayed
without alternating with a vat number, a problem may
exist with the MIB board itself.
Press the M button, which switches the board to manual. The display becomes
the number of the vat to be controlled manually.
Press the vat selector button until the desired vat number is displayed.
Press either the drain or return button to drain or return oil to the vat displayed.
Pressing both allows fi ltration.
Pressing the M button again returns the board to automatic mode.
1.
2.
3.
4.
Manual Draining, Filling, Filtering with MIB
2
1
3
Error Codes
