Basic Operation 17
Main Components
Front View
Rear View
1 Operator Panel 2 Center Output Tray
3 Output Tray Extension 4 Print Head Cleaning Rod
5 Toner Access Cover 6 Power Switch
7 Standard 150 Sheet Tray
1 Power Connector 2 Rear Cover Handle
3 USB Port 4 Ethernet Port
5 Rear Cover 6 Transfer Roller
7 Paper Chute 8 Paper Feed Roller
9 Transfer Belt 10 Levers
