78 Printing Basics
Supported Print Media
Using unsuitable print media may lead to paper jams, poor print quality, breakdown and damage to your printer. To
use the features of this printer effectively, use the suggested print media that is recommended here.
IMPORTANT:
• The toner may come off the print media if it gets wet by water, rain, steam, and so on. For details, contact the Fuji Xerox local
representative office or an authorized dealer.
Usable Print Media
The types of print media that can be used on this printer are as follows:
Standard 150 Sheet Tray
*
Monarch and DL envelopes can be supported by LEF with their flaps open.
NOTE:
• SEF and LEF indicate the paper feed direction; SEF stands for short-edge feed. LEF stands for long-edge feed.
• Use only laser print media. Do not use ink jet paper in this printer.
See also:
• "Loading Print Media in the Standard 150 Sheet Tray" on page 79
• "Loading Envelope in the Standard 150 Sheet Tray" on page 82
• "Loading Letterhead in the Standard 150 Sheet Tray" on page 83
Using print media, which is different from the paper size or paper type set on the print driver, may lead to paper jams.
To make sure that printing is correctly performed, select the correct paper size and paper type.
Paper Size A4 SEF (210 297 mm)
B5 SEF (182
257 mm)
A5 SEF (148
210 mm)
Letter SEF (8.5
11 inches)
Legal SEF (8.5
14 inches)
Folio SEF (8.5
13 inches)
Executive SEF (7.25
10.5 inches)
C5 SEF (162
229 mm)
Monarch SEF (3.875
7.5 inches)
Monarch LEF (7.5
3.875 inches)
*
Com 10 Env SEF (4.125 9.5 inches)
DL SEF (110
220 mm)
DL LEF (220
110 mm)
*
Custom Size:
Width: 76.2 – 215.9 mm (3 – 8.5 inches)
Length: 127 – 355.6 mm (5 – 14 inches)
Paper Type (Weight) Plain (60 – 90 gsm)
Bond (91 – 105 gsm)
Lightweight Cardstock (106 – 163 gsm)
Lightweight Glossy Cardstock (106 – 163 gsm)
Envelope
Labels
Recycled (60 – 105 gsm)
Loading Capacity 150 sheets of standard paper
