Printer Connection and Software Installation 41
16 Select Subnet Mask, and then press the button.
The first three digits of the subnet mask are selected.
17 Enter the value using the or button.
18 Press the button.
The next three digits are selected.
19 Repeat steps 17 to 18 to set subnet mask, and then press the button.
20 Press the (Back) button.
21 Confirm that Subnet Mask appears.
22 Select Gateway Address, and then press the button.
The first three digits of the gateway address are selected.
23 Enter the value of the gateway address using the or button.
24 Press the button.
The next three digits are selected.
25 Repeat steps 23 to 24 to set gateway address, and then press the button.
26 Turn off and turn on the printer.
See also:
• "Operator Panel" on page 18
Using the Printer Setting Utility (Windows Only)
The following procedure uses Windows 7 as an example.
1 Click Start All Programs Fuji Xerox Fuji Xerox Printer Software for Asia-Pacific your printer
Printer Setting Utility.
NOTE:
• The window to select a printer appears in this step when multiple print drivers are installed on your computer. In this
case, click the name of the desired printer listed in Printer Name.
The Printer Setting Utility appears.
2 Click the Printer Maintenance tab.
3 Select TCP/IP Settings from the list at the left side of the page.
The TCP/IP Settings page is displayed.
4 Select Panel from IP Address Mode, and then enter the values in IP Address, Subnet Mask, and Gateway
Address.
5 Click Restart printer to apply new settings to take effect.
