12 Installing/Removing Optional Components
272
Installing the Storage
Once installed, the storage (optional) is exclusive to the device to prevent data leaks. It cannot be removed
and attached to another device.
1
Press the power button and select [Power Off Device] to switch off the power.
The electrical components inside the back cover of the device may be hot. When installing, be sure to turn off
the power, and after about 40 minutes, make sure that the inside of the device has cooled down.
2
Slide the latch on the rear left side in the direction of the arrow and lift it towards you.
3
Remove the left side cover by sliding it toward the back of the device.
If the storage (optional) has already been installed, remove it.
To Next Page
