Printer Connection and Software Installation
138
• Using Ad Hoc Connection
To configure the wireless settings for an ad-hoc connection where the wireless devices communicate
directly with each other without an access point:
1
On the operator panel, press the System button.
2
Select Admin Menu, and then press the button.
3
Select Network, and then press the button.
4
Select Wireless Setup, and then press the button.
5
Select Manual Setup, and then press the button.
6
Enter the SSID, and then press the button.
Use the numeric keypad to enter the desired value, and press the or button to move a
cursor.
7
Select Ad-hoc, and then press the button.
8
Select an encryption type, and then press the button.
IMPORTANT:
• Be sure to use one of the supported encryption methods to protect your network traffic.
9
Enter the WEP key, and then press the button.
Use the numeric keypad to enter the desired value, and press the or button to move a
cursor.
10
Select a transmit key.
11
Wait a few minutes until the printer restarts to establish the wireless network.
12
Print a System Settings page from the operator panel.
See "Printing a System Settings Page" on page 194.
13
Confirm that "Link Quality" is shown as "Good", "Acceptable" or "Low" on the report.
NOTE:
• When "Link Quality" is "No Reception", check if the wireless settings are correctly configured.
Auto Setup With the Access Point
If the access point such as a wireless router supports the WPS, security settings can be made
automatically.
