270 Maintenance
Installing the Feed Roll and Nudger Roll
1 Unpack a new feed roll and nudger roll.
NOTE:
• The feed roll and nudger roll have the same shape. There is no difference between the replacement rollers.
2 Insert the nudger roll into the right shaft. Set the knob of the roller into the notches of the clutch.
3 Insert the feed roll into the left shaft. Set the knob of the roller into the notches of the clutch.
NOTE:
• Make sure that the feed roll and nudger roll are firmly set in the shaft and cannot be moved easily.
4 Hold the printer with both hands, and gently place the printer upright.
To Next Page
