Rear View
*: The optional wireless printer adapter is not supplied in some regions.
1 Control Board 7 Power Connector
2 Control Board Cover 8 Chute
3 Power Switch 9 Duplexer
4 Ethernet Port 10 Transfer Unit
5 USB Port 11 Fusing Unit
6 Wireless Adapter Socket
*
12 Rear Door
1
2
3
5
4
6
7
9
10
11
12
8
