4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and
the indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢
Model: AUYG18LVLB
AFR
m
3
/h
680
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 4.45 3.17 0.44 4.96 3.18 0.44 5.13 3.46 0.44 5.47 3.47 0.45 5.64 3.75 0.45 5.97 3.74 0.46 6.31 3.98 0.46
0 4.35 3.11 0.51 4.85 3.13 0.52 5.01 3.40 0.52 5.34 3.41 0.52 5.51 3.69 0.53 5.84 3.67 0.53 6.17 3.91 0.54
5 4.23 3.06 0.63 4.71 3.08 0.64 4.87 3.35 0.64 5.19 3.36 0.65 5.35 3.63 0.65 5.67 3.62 0.66 6.00 3.85 0.66
10 4.09 3.00 0.74 4.56 3.02 0.75 4.71 3.28 0.76 5.02 3.29 0.76 5.18 3.56 0.77 5.49 3.54 0.78 5.80 3.78 0.78
15 4.10 3.01 0.65 4.57 3.03 0.66 4.72 3.29 0.66 5.04 3.30 0.67 5.19 3.57 0.67 5.50 3.55 0.68 5.82 3.78 0.69
20 4.68 3.13 1.36 5.22 3.15 1.38 5.40 3.42 1.39 5.75 3.44 1.40 5.93 3.71 1.41 6.29 3.70 1.42 6.64 3.94 1.44
25 4.50 3.13 1.43 5.01 3.15 1.45 5.18 3.42 1.46 5.52 3.44 1.47 5.69 3.71 1.48 6.03 3.70 1.49 6.37 3.94 1.51
30 4.30 3.12 1.50 4.79 3.14 1.52 4.95 3.42 1.53 5.28 3.43 1.54 5.44 3.70 1.55 5.77 3.69 1.57 6.09 3.93 1.58
35 4.11 3.12 1.56 4.58 3.14 1.59 4.73 3.42 1.60 5.04 3.43 1.61 5.20 3.70 1.62 5.51 3.69 1.64 5.82 3.93 1.65
40 3.59 2.80 1.43 4.00 2.82 1.45 4.13 3.06 1.46 4.40 3.07 1.47 4.54 3.32 1.48 4.81 3.31 1.49 5.09 3.52 1.51
46 2.58 2.41 1.08 2.87 2.43 1.10 2.97 2.64 1.10 3.17 2.65 1.11 3.27 2.86 1.12 3.46 2.85 1.13 3.66 3.03 1.14
¢
Model: AUYG24LVLA
AFR
m
3
/h
930
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-10 5.62 4.52 0.60 6.26 4.54 0.60 6.47 4.94 0.61 6.90 4.95 0.61 7.11 5.35 0.62 7.54 5.33 0.62 7.96 5.68 0.63
0 5.52 4.47 0.64 6.15 4.49 0.65 6.36 4.89 0.66 6.78 4.90 0.66 6.99 5.29 0.67 7.41 5.27 0.67 7.83 5.62 0.68
5 5.33 4.37 0.78 5.94 4.40 0.79 6.14 4.78 0.80 6.55 4.80 0.80 6.75 5.18 0.81 7.15 5.16 0.82 7.56 5.50 0.82
10 5.12 4.26 0.91 5.71 4.29 0.92 5.90 4.66 0.93 6.29 4.68 0.94 6.49 5.05 0.94 6.87 5.03 0.95 7.26 5.36 0.96
15 5.25 4.33 0.76 5.85 4.35 0.77 6.05 4.73 0.78 6.45 4.75 0.79 6.65 5.13 0.79 7.05 5.11 0.80 7.44 5.44 0.81
20 6.08 4.56 1.52 6.78 4.58 1.55 7.01 4.98 1.56 7.47 5.00 1.57 7.70 5.40 1.58 8.16 5.38 1.60 8.62 5.73 1.61
25 5.85 4.43 1.73 6.51 4.46 1.75 6.73 4.85 1.76 7.18 4.86 1.78 7.40 5.25 1.79 7.84 5.23 1.81 8.29 5.57 1.83
30 5.61 4.31 1.93 6.25 4.34 1.96 6.46 4.72 1.97 6.89 4.73 1.99 7.10 5.11 2.00 7.53 5.09 2.02 7.95 5.42 2.04
35 5.37 4.19 2.13 5.98 4.21 2.17 6.19 4.58 2.18 6.60 4.59 2.20 6.80 4.96 2.21 7.21 4.94 2.23 7.62 5.26 2.25
40 5.22 4.31 2.10 5.81 4.34 2.14 6.01 4.72 2.15 6.41 4.73 2.17 6.61 5.11 2.18 7.00 5.09 2.20 7.40 5.42 2.22
46 3.74 3.58 1.59 4.17 3.60 1.61 4.31 3.91 1.62 4.60 3.92 1.64 4.74 4.24 1.65 5.02 4.22 1.66 5.31 4.50 1.68
- 7 -
CASSETTE TYPE
AUYG18-24LVL
