2. Dimensions
2-1. Model: AOYG18LBCB
Side viewSide view
Front view
Pitch of bolts for installation
Top view
Pitch of bolts
for installation
Unit: mm
2-2. Model: AOYG24LBCB
Side view
Side view
Front view
Pitch of bolts for installation
Top view
Pitch of bolts
for installation
Unit: mm
315
- 39 -
OUTDOOR UNIT
AOYG18-24LBCB
