4-2. Heating capacity
NOTE:
Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AUYG18LVLB
AFR
m
3
/h
800
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 5.01 2.50 4.89 2.55 4.77 2.60 4.65 2.65 4.53 2.71
-10 -11 5.76 2.61 5.62 2.67 5.49 2.72 5.35 2.77 5.21 2.83
-5 -7 6.49 2.69 6.34 2.74 6.18 2.80 6.03 2.83 5.87 2.83
0 -2 7.35 2.72 7.18 2.77 7.00 2.83 6.83 2.83 6.65 2.83
5 3 7.73 2.51 7.54 2.56 7.36 2.61 7.18 2.66 6.99 2.71
7 6 7.87 2.42 7.69 2.47 7.50 2.52 7.31 2.57 7.12 2.62
10 8 8.12 2.43 7.92 2.48 7.73 2.53 7.54 2.58 7.34 2.63
15 10 7.79 2.13 7.61 2.17 7.42 2.22 7.23 2.26 7.05 2.31
20 15 7.17 1.64 7.00 1.67 6.83 1.71 6.66 1.74 6.49 1.77
24 18 7.39 1.65 7.21 1.68 7.03 1.71 6.86 1.75 6.68 1.78
¢
Model: AUYG24LVLA
AFR
m
3
/h
930
Indoor temperature
°CDB 16 18 20 22 24
Outdoor temperature
°CDB °CWB
TC IP TC IP TC IP TC IP TC IP
kW kW kW kW kW
-15 -16 6.15 2.84 6.01 2.90 5.86 2.96 5.72 3.01 5.57 3.07
-10 -11 6.92 3.03 6.75 3.09 6.59 3.15 6.42 3.22 6.26 3.28
-5 -7 7.64 3.02 7.45 3.08 7.27 3.14 7.09 3.20 6.91 3.27
0 -2 8.59 3.00 8.38 3.06 8.18 3.12 7.97 3.18 7.77 3.25
5 3 9.28 2.77 9.06 2.83 8.84 2.89 8.62 2.95 8.40 3.01
7 6 9.55 2.69 9.33 2.74 9.10 2.80 8.87 2.86 8.64 2.91
10 8 9.87 2.69 9.63 2.75 9.40 2.80 9.16 2.86 8.93 2.92
15 10 8.97 2.07 8.76 2.12 8.54 2.16 8.33 2.20 8.11 2.25
20 15 8.23 1.63 8.03 1.66 7.84 1.69 7.64 1.73 7.45 1.76
24 18 8.52 1.62 8.32 1.66 8.12 1.69 7.92 1.73 7.71 1.76
DESIGN & TECHNICAL MANUAL
- 8 -
CASSETTE TYPE
AUYG18-24LVL
