1. Specifications
Type
Cassette
Inverter heat pump
Model name AUYG18LVLB AUYG24LVLA
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 5.20 6.80
Btu/h 17,700 23,200
Min.—Max.
kW 0.90 - 5.90 0.90 - 8.00
Btu/h 3,100 - 20,100 3,100 - 27,300
Heating
Rated
kW 6.00 8.00
Btu/h 20,500 27,300
Min.—Max.
kW 0.90 - 7.50 0.90 - 9.10
Btu/h 3,100 - 25,600 3,100 - 31,000
Input power
Cooling
Rated
kW
1.62 2.21
Max. 2.04 2.85
Heating
Rated 1.66 2.26
Max. 2.83 3.19
Current
Cooling
Rated A
7.2 9.7
Heating 7.4 9.9
Power factor
Cooling
%
97.8 99.1
Heating 97.5 99.3
EER Cooling
kW/kW
3.21 3.08
COP Heating 3.61 3.54
Moisture removal L/h (pints/h) 2.2 ( 3.9 ) 2.7 ( 4.8 )
Maximum operating current *1
Cooling
A
11.5 14.7
Heating 13.5 15.7
Fan
Airflow rate
Cooling
HIGH
m
3
/h
680 930
MED 580 830
LOW 490 600
QUIET 410 450
Heating
HIGH 800 930
MED 680 860
LOW 580 700
QUIET 450 530
Type × Q'ty Turbo × 1
Motor output W 54
Sound pressure level *2
Cooling
HIGH
dB (A)
38 49
MED 34 44
LOW 30 36
QUIET 26 30
Heating
HIGH 43 49
MED 38 45
LOW 34 40
QUIET 30 33
Sound power level
Cooling
HIGH dB (A)
50 59
Heating 55 61
Heat exchanger type
Dimensions (H × W × D)
mm
210 × 1,310 × 13.3
210 × 1,250 × 13.3
210 × 1,360 × 13.3
210 × 1,295 × 13.3
210 × 1,235 × 13.3
Fin pitch 1.2 1.45
Rows × Stages 2 × 10 3 × 10
Pipe type Copper tube
Fin type Aluminum
Dimensions
(H × W × D)
Net
mm
245 × 570 × 570
Gross 265 × 730 × 625
Weight
Net
kg
15 16
Gross 18 19
Connection
pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1 / 4 in.)
Gas Ø12.70 (Ø1/2 in.) Ø15.88 (Ø5/8 in.)
Method Flare
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Cassette grille
(Option)
Material Hi-PS
Color White Approximate color of Munsell N 9.25 /
Dimensions
(H × W × D)
Net
mm
49 × 700 × 700
Gross 120 × 765 × 755
Weight
Net
kg
2.6
Gross 4.5
Remote controller Wireless [Wired (option)]
Drain hose
Material PVC
Size mm VP25 [Ø25(I.D.),Ø32(O.D.)]
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m. (Between outdoor unit and indoor unit.)
• Protective function might work when using it outside the operation range.
• *1: Maximum current:
– The maximum value when operated within the operation range.
– The total current of indoor unit and outdoor unit.
• *2: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
DESIGN & TECHNICAL MANUAL
- 2 -
CASSETTE TYPE AUYG18-24LVL

Fujitsu AOYG18LBCB Specifications

General

Type	Air conditioner outdoor unit
Ionizer	No
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Hose length (min)	15 m
Remotely operated	Yes
Drain hose diameter	32 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Seasonal efficiency rating (heating) (SCOP)	4.2
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	11.5 A
Current (heating)	13.5 A
AC input frequency	50 Hz
Design load (cooling)	298 kW
Energy efficiency class (cooling)	A++
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Design load (heating) (Average heating season)	1819 kW
Energy efficiency class (heating) (Warmer heating season)	A+
Outdoor unit depth	290 mm
Outdoor unit width	799 mm
Outdoor unit height	632 mm
Outdoor unit weight	36000 g
Outdoor units quantity	1
Outdoor unit noise level	50 dB
Cooling airflow (outdoor unit)	2380 m³/h
Indoor unit noise level (high speed)	- dB
