12-2. Cassette grille
Exterior Part name Model name Summary
Cassette grille UTG-UFYD-W
The form of grille discharges wind
away from the ceiling making it
difficult to leave dirt marks.
12-3. Others
Exterior Part name Model name Summary
External
connect kit
UTY-XWZX
Use to connect with various
peripheral devices and air conditioner
PCB.
Air outlet
shutter plate
UTR-YDZB
Installed at the air outlet when 3-
directions mode is performed.
Fresh-air intake
kit
UTZ-VXAA
By attaching Fresh-air intake kit to
the indoor unit, it can be taken in
fresh air of up to 10% of “high” air
volume of the indoor unit.
Insulation for
high humidity
UTZ-KXGC
Install when the under-roof condition
is expected to be the humidity of over
80% and the temperature of over
30 °C.
- 35 -
CASSETTE TYPE
AUYG18-24LVL
