Fujitsu AOYG18LBCB User Manual

1. Specifications
Type Inverter heat pump
Model name AOYG18LBCB AOYG24LBCB
Power supply 230 V ~ 50 Hz
Available voltage range 198—264 V
Starting current A 7.4 9.9
Fan
Airflow rate
Cooling
m
3
/h
2,380 2,850
Heating 2,080 2,700
Type × Q'ty Propeller × 1
Motor output W 49
Sound pressure level *1
Cooling
dB (A)
50 53
Heating 50 54
Sound power level
Cooling
dB (A)
62 66
Heating 65 66
Heat exchanger type
Dimensions
(H × W × D)
mm
588 × 881 × 18.19
588 × 851 × 18.19
672 × 881 × 18.19
672 × 851 × 18.19
Fin pitch 1.3
Rows × Stages 2 × 28 2 × 32
Pipe type Copper
Fin type
Type (Material) Corrugate (Aluminum)
Surface treatment Corrosion resistance
Compressor
Type × Q'ty Twin rotary × 1
Motor output W 900 1,200
Refrigerant
Type (Global warming potential) R410A
Charge g 1,200 1,500
Refrigerant oil
Type FV50S RB68
Amount
cm
3
400 550
Enclosure
Material Steel sheet
Color
Beige
Approximate color of Munsell 10YR 7.5/1.0
Dimensions
(H × W × D)
Net
mm
632 × 799 × 290 716 × 820 × 315
Gross 692 × 940 × 375 776 × 961 × 450
Weight
Net
kg
36 42
Gross 40 47
Connection pipe
Size
Liquid
mm (in)
Ø 6.35 (Ø 1/4) Ø 6.35 (Ø 1/4)
Gas Ø 12.70 (Ø 1/2) Ø 15.88 (Ø 5/8)
Method Flare
Pre-charge length
m
15 15
Max. length 25 30
Max. height difference 15 20
Operation range
Cooling
°C
-10 to 46
Heating -15 to 24
Drain hose
Material PP+LLDPE
Size mm Ø 13.0 (I. D.), Ø 16.0 to Ø 16.8 (O. D.)
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19 °CWB, and outdoor temperature of 35 °CDB/24 °CWB.
– Heating: Indoor temperature of 20 °CDB/15 °CWB, and outdoor temperature of 7 °CDB/6 °CWB.
– Pipe length: 5 m, Height difference: 0 m.
• Protective function might work when using it outside the operation range.
• *1: Sound pressure level
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
DESIGN & TECHNICAL MANUAL
- 38 -
OUTDOOR UNIT AOYG18-24LBCB

Fujitsu AOYG18LBCB Specifications

General

Type	Air conditioner outdoor unit
Ionizer	No
Multi-split	-
Product color	White
Gas hose diameter	12.7 mm
Hose length (max)	25 m
Hose length (min)	15 m
Remotely operated	Yes
Drain hose diameter	32 mm
Liquid hose diameter	6.35 mm
Refrigerating medium	R410A
Dehumidifying capacity	2 l/h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (nominal)	5200 W
Cooling energy efficiency (EER, W/W)	3.21
Heating energy efficiency (COP, W/W)	3.61
Operating temperature (cooling) (T-T)	-10 - 46 °C
Operating temperature (heating) (T-T)	-15 - 24 °C
Seasonal efficiency rating (cooling) (SEER)	6.1
Seasonal efficiency rating (heating) (SCOP)	4.2
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	6000 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	4
AC input voltage	230 V
Current (cooling)	11.5 A
Current (heating)	13.5 A
AC input frequency	50 Hz
Design load (cooling)	298 kW
Energy efficiency class (cooling)	A++
Hourly energy consumption (cooling)	- kWh
Design load (heating) (Warmer heating season)	- kW
Design load (heating) (Average heating season)	1819 kW
Energy efficiency class (heating) (Warmer heating season)	A+
Outdoor unit depth	290 mm
Outdoor unit width	799 mm
Outdoor unit height	632 mm
Outdoor unit weight	36000 g
Outdoor units quantity	1
Outdoor unit noise level	50 dB
Cooling airflow (outdoor unit)	2380 m³/h
Indoor unit noise level (high speed)	- dB
