Fujitsu AOYG24KBTA3 Design & Technical Manual

10. Electrical characteristics
Power supply
(50 Hz, 230 V)
Indoor rated
Wiring spec. of connection
cable
(Indoor unit to outdoor
unit)
Type Model name
MCA
Input
power
FLA
Cross-
sectional
area
Limited
wiring
length
(A) (W) (A)
(mm
2
)
(m)
Compact cassette
AUXG07KVLA 0.19 18 0.15
1.5 26
AUXG09KVLA 0.19 18 0.15
AUXG12KVLA 0.24 23 0.19
AUXG14KVLA 0.28 28 0.22
AUXG18KVLA 0.38 39 0.30
Mini duct
ARXG07KSLAP 0.33 33 0.29
1.5 26
ARXG09KSLAP 0.38 40 0.33
ARXG12KSLAP 0.42 47 0.38
ARXG14KSLAP 0.67 72 0.58
ARXG18KSLAP 0.61 63 0.49
Slim duct
ARXG07KLLAP 0.41 33 0.33
1.5 26
ARXG09KLLAP 0.38 49 0.30
ARXG12KLLAP 0.44 58 0.35
ARXG14KLLAP 0.64 76 0.51
ARXG18KLLAP 0.55 73 0.44
Wall mounted
ASYG07KGTB 0.25 23 0.20
1.5 26
ASYG09KGTB 0.30 27 0.24
ASYG12KGTB 0.30 27 0.24
ASYG14KGTB 0.37 33 0.29
ASYG07KGTE 0.25 23 0.20
ASYG09KGTE 0.30 27 0.24
ASYG12KGTE 0.30 27 0.24
ASYG14KGTE 0.37 33 0.29
ASYG07KGTF 0.25 23 0.20
ASYG09KGTF 0.30 27 0.24
ASYG12KGTF 0.30 27 0.24
ASYG14KGTF 0.37 33 0.29
ASYG18KMTB 0.44 38 0.35
ASYG18KMTE 0.44 38 0.35
ASYG07KMTB 0.25 23 0.20
ASYG09KMTB 0.30 27 0.24
ASYG12KMTB 0.30 27 0.24
ASYG14KMTB 0.38 33 0.30
ASYG07KMCC 0.25 23 0.20
ASYG09KMCC 0.30 27 0.24
ASYG12KMCC 0.30 27 0.24
ASYG14KMCC 0.38 33 0.30
ASYG07KMCE 0.25 23 0.20
ASYG09KMCE 0.30 27 0.24
ASYG12KMCE 0.30 27 0.24
ASYG14KMCE 0.38 33 0.30
ASYG07KMCF 0.25 23 0.20
ASYG09KMCF 0.30 27 0.24
ASYG12KMCF 0.30 27 0.24
ASYG14KMCF 0.38 33 0.30
- 155 -
10. Electrical characteristics
3-UNIT MULTI-SPLIT TYPE 3-UNIT MULTI-SPLIT TYPE
