Fujitsu AOYG24KBTA3 Design & Technical Manual

6-3. Heating capacity
NOTE: Values mentioned in the table are calculated based on the maximum capacity.
¢
Model: AOYG18KBTA3
Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
30
-15.0
-16.0 6.4 3.03 6.3 3.09 6.1 3.15 5.9 3.21 5.8 3.28
-10.0 -11.0 7.2 3.21 7.1 3.27 6.9 3.34 6.7 3.41 6.5 3.47
-5.0 -7.0 7.7 2.92 7.5 2.98 7.4 3.04 7.2 3.10 7.0 3.16
0.0 -2.0 8.4 2.60 8.2 2.66 8.0 2.71 7.8 2.77 7.6 2.82
5.0 3.0 8.4 2.02 8.2 2.07 8.0 2.11 7.8 2.15 7.6 2.19
7.0 6.0 8.4 1.78 8.2 1.81 8.0 1.85 7.8 1.89 7.6 1.92
10.0 8.0 8.4 1.67 8.2 1.70 8.0 1.74 7.8 1.77 7.6 1.81
15.0 10.0 8.4 1.51 8.2 1.54 8.0 1.57 7.8 1.61 7.6 1.64
20.0 15.0 8.4 1.28 8.2 1.30 8.0 1.33 7.8 1.36 7.6 1.38
24.0 18.0 8.4 1.14 8.2 1.17 8.0 1.19 7.8 1.22 7.6 1.24
28
-15.0
-16.0 6.4 3.03 6.3 3.09 6.1 3.15 5.9 3.21 5.8 3.28
-10.0 -11.0 7.2 3.21 7.1 3.27 6.9 3.34 6.7 3.41 6.5 3.47
-5.0 -7.0 7.7 2.92 7.5 2.98 7.4 3.04 7.2 3.10 7.0 3.16
0.0 -2.0 8.4 2.60 8.2 2.66 8.0 2.71 7.8 2.77 7.6 2.82
5.0 3.0 8.4 2.02 8.2 2.07 8.0 2.11 7.8 2.15 7.6 2.19
7.0 6.0 8.4 1.78 8.2 1.81 8.0 1.85 7.8 1.89 7.6 1.92
10.0 8.0 8.4 1.67 8.2 1.70 8.0 1.74 7.8 1.77 7.6 1.81
15.0 10.0 8.4 1.51 8.2 1.54 8.0 1.57 7.8 1.61 7.6 1.64
20.0 15.0 8.4 1.28 8.2 1.30 8.0 1.33 7.8 1.36 7.6 1.38
24.0 18.0 8.4 1.14 8.2 1.17 8.0 1.19 7.8 1.22 7.6 1.24
27
-15.0
-16.0 6.4 3.03 6.3 3.09 6.1 3.15 5.9 3.21 5.8 3.28
-10.0 -11.0 7.2 3.21 7.1 3.27 6.9 3.34 6.7 3.41 6.5 3.47
-5.0 -7.0 7.7 2.92 7.5 2.98 7.4 3.04 7.2 3.10 7.0 3.16
0.0 -2.0 8.4 2.60 8.2 2.66 8.0 2.71 7.8 2.77 7.6 2.82
5.0 3.0 8.4 2.02 8.2 2.07 8.0 2.11 7.8 2.15 7.6 2.19
7.0 6.0 8.4 1.78 8.2 1.81 8.0 1.85 7.8 1.89 7.6 1.92
10.0 8.0 8.4 1.67 8.2 1.70 8.0 1.74 7.8 1.77 7.6 1.81
15.0 10.0 8.4 1.51 8.2 1.54 8.0 1.57 7.8 1.61 7.6 1.64
20.0 15.0 8.4 1.28 8.2 1.30 8.0 1.33 7.8 1.36 7.6 1.38
24.0 18.0 8.4 1.14 8.2 1.17 8.0 1.19 7.8 1.22 7.6 1.24
26
-15.0
-16.0 6.4 3.03 6.3 3.09 6.1 3.15 5.9 3.21 5.8 3.28
-10.0 -11.0 7.2 3.21 7.1 3.27 6.9 3.34 6.7 3.41 6.5 3.47
-5.0 -7.0 7.7 2.92 7.5 2.98 7.4 3.04 7.2 3.10 7.0 3.16
0.0 -2.0 8.4 2.60 8.2 2.66 8.0 2.71 7.8 2.77 7.6 2.82
5.0 3.0 8.4 2.02 8.2 2.07 8.0 2.11 7.8 2.15 7.6 2.19
7.0 6.0 8.4 1.78 8.2 1.81 8.0 1.85 7.8 1.89 7.6 1.92
10.0 8.0 8.4 1.67 8.2 1.70 8.0 1.74 7.8 1.77 7.6 1.81
15.0 10.0 8.4 1.51 8.2 1.54 8.0 1.57 7.8 1.61 7.6 1.64
20.0 15.0 8.4 1.28 8.2 1.30 8.0 1.33 7.8 1.36 7.6 1.38
24.0 18.0 8.4 1.14 8.2 1.17 8.0 1.19 7.8 1.22 7.6 1.24
25
-15.0
-16.0 6.4 3.03 6.3 3.09 6.1 3.15 5.9 3.21 5.8 3.28
-10.0 -11.0 7.2 3.21 7.1 3.27 6.9 3.34 6.7 3.41 6.5 3.47
-5.0 -7.0 7.7 2.92 7.5 2.98 7.4 3.04 7.2 3.10 7.0 3.16
0.0 -2.0 8.4 2.60 8.2 2.66 8.0 2.71 7.8 2.77 7.6 2.82
5.0 3.0 8.4 2.02 8.2 2.07 8.0 2.11 7.8 2.15 7.6 2.19
7.0 6.0 8.4 1.78 8.2 1.81 8.0 1.85 7.8 1.89 7.6 1.92
10.0 8.0 8.4 1.67 8.2 1.70 8.0 1.74 7.8 1.77 7.6 1.81
15.0 10.0 8.4 1.51 8.2 1.54 8.0 1.57 7.8 1.61 7.6 1.64
20.0 15.0 8.4 1.28 8.2 1.30 8.0 1.33 7.8 1.36 7.6 1.38
24.0 18.0 8.4 1.14 8.2 1.17 8.0 1.19 7.8 1.22 7.6 1.24
24
-15.0
-16.0 6.4 3.03 6.3 3.09 6.1 3.15 5.9 3.21 5.8 3.28
-10.0 -11.0 7.2 3.21 7.1 3.27 6.9 3.34 6.7 3.41 6.5 3.47
-5.0 -7.0 7.7 2.92 7.5 2.98 7.4 3.04 7.2 3.10 7.0 3.16
0.0 -2.0 8.4 2.60 8.2 2.66 8.0 2.71 7.8 2.77 7.6 2.82
5.0 3.0 8.4 2.02 8.2 2.07 8.0 2.11 7.8 2.15 7.6 2.19
7.0 6.0 8.4 1.78 8.2 1.81 8.0 1.85 7.8 1.89 7.6 1.92
10.0 8.0 8.4 1.67 8.2 1.70 8.0 1.74 7.8 1.77 7.6 1.81
15.0 10.0 8.4 1.51 8.2 1.54 8.0 1.57 7.8 1.61 7.6 1.64
20.0 15.0 8.4 1.28 8.2 1.30 8.0 1.33 7.8 1.36 7.6 1.38
24.0 18.0 8.4 1.14 8.2 1.17 8.0 1.19 7.8 1.22 7.6 1.24
23
-15.0
-16.0 6.4 3.03 6.3 3.09 6.1 3.15 5.9 3.21 5.8 3.28
-10.0 -11.0 7.2 3.21 7.1 3.27 6.9 3.34 6.7 3.41 6.5 3.47
-5.0 -7.0 7.7 2.92 7.5 2.98 7.4 3.04 7.2 3.10 7.0 3.16
0.0 -2.0 8.4 2.60 8.2 2.66 8.0 2.71 7.8 2.77 7.6 2.82
5.0 3.0 8.4 2.02 8.2 2.07 8.0 2.11 7.8 2.15 7.6 2.19
7.0 6.0 8.4 1.78 8.2 1.81 8.0 1.85 7.8 1.89 7.6 1.92
10.0 8.0 8.4 1.67 8.2 1.70 8.0 1.74 7.8 1.77 7.6 1.81
15.0 10.0 8.4 1.51 8.2 1.54 8.0 1.57 7.8 1.61 7.6 1.64
20.0 15.0 8.4 1.28 8.2 1.30 8.0 1.33 7.8 1.36 7.6 1.38
24.0 18.0 8.4 1.14 8.2 1.17 8.0 1.19 7.8 1.22 7.6 1.24
21
-15.0
-16.0 6.4 3.03 6.3 3.09 6.1 3.15 5.9 3.21 5.8 3.28
-10.0 -11.0 7.2 3.21 7.1 3.27 6.9 3.34 6.7 3.41 6.5 3.47
-5.0 -7.0 7.7 2.92 7.5 2.98 7.4 3.04 7.2 3.10 7.0 3.16
0.0 -2.0 8.4 2.60 8.2 2.66 8.0 2.71 7.8 2.77 7.6 2.82
5.0 3.0 8.4 2.02 8.2 2.07 8.0 2.11 7.8 2.15 7.6 2.19
7.0 6.0 8.4 1.78 8.2 1.81 8.0 1.85 7.8 1.89 7.6 1.92
10.0 8.0 8.4 1.67 8.2 1.70 8.0 1.74 7.8 1.77 7.6 1.81
15.0 10.0 8.4 1.51 8.2 1.54 8.0 1.57 7.8 1.61 7.6 1.64
20.0 15.0 8.4 1.28 8.2 1.30 8.0 1.33 7.8 1.36 7.6 1.38
24.0 18.0 8.4 1.14 8.2 1.17 8.0 1.19 7.8 1.22 7.6 1.24
- 392 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
