2. Dimensions
2-1. Models: AOYG18KBTA3 and AOYG24KBTA3
Unit: mm
Side viewSide view Front view
Top view
16 315
20 18
Airflow
600
109
353 330
Pitch of bolts for installation
Pitch of bolts for installation
4-
M1 0 hole
82019
99
716
20
Drain port Ø42
37
410
Bottom view
Side view (Valve part)
92
168
71
17
46
92×2=184
