Fujitsu AOYG24KBTA3 Design & Technical Manual

¢
Model: AOYG24KBTA3
Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
36
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
35
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
34
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
33
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
32
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
31
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
30
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
- 370 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
