Fujitsu AOYG24KBTA3 Design & Technical Manual

¢
Model: AOYG24KBTA3
Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
36
-15.0
-16.0 6.5 3.05 6.3 3.12 6.2 3.18 6.0 3.25 5.9 3.31
-10.0 -11.0 7.3 3.24 7.1 3.30 7.0 3.37 6.8 3.44 6.6 3.51
-5.0 -7.0 7.8 2.95 7.6 3.01 7.4 3.07 7.2 3.13 7.1 3.19
0.0 -2.0 8.9 2.63 8.7 2.68 8.5 2.74 8.3 2.79 8.1 2.85
5.0 3.0 9.7 2.56 9.4 2.61 9.2 2.67 9.0 2.72 8.7 2.77
7.0 6.0 9.7 2.25 9.4 2.30 9.2 2.34 9.0 2.39 8.7 2.44
10.0 8.0 9.7 2.11 9.4 2.16 9.2 2.20 9.0 2.24 8.7 2.29
15.0 10.0 9.7 1.91 9.4 1.95 9.2 1.99 9.0 2.03 8.7 2.07
20.0 15.0 9.7 1.61 9.4 1.65 9.2 1.68 9.0 1.72 8.7 1.75
24.0 18.0 9.7 1.45 9.4 1.48 9.2 1.51 9.0 1.54 8.7 1.57
35
-15.0
-16.0 6.5 3.05 6.3 3.12 6.2 3.18 6.0 3.25 5.9 3.31
-10.0 -11.0 7.3 3.24 7.1 3.30 7.0 3.37 6.8 3.44 6.6 3.51
-5.0 -7.0 7.8 2.95 7.6 3.01 7.4 3.07 7.2 3.13 7.1 3.19
0.0 -2.0 8.9 2.63 8.7 2.68 8.5 2.74 8.3 2.79 8.1 2.85
5.0 3.0 9.7 2.56 9.4 2.61 9.2 2.67 9.0 2.72 8.7 2.77
7.0 6.0 9.7 2.25 9.4 2.30 9.2 2.34 9.0 2.39 8.7 2.44
10.0 8.0 9.7 2.11 9.4 2.16 9.2 2.20 9.0 2.24 8.7 2.29
15.0 10.0 9.7 1.91 9.4 1.95 9.2 1.99 9.0 2.03 8.7 2.07
20.0 15.0 9.7 1.61 9.4 1.65 9.2 1.68 9.0 1.72 8.7 1.75
24.0 18.0 9.7 1.45 9.4 1.48 9.2 1.51 9.0 1.54 8.7 1.57
34
-15.0
-16.0 6.5 3.05 6.3 3.12 6.2 3.18 6.0 3.25 5.9 3.31
-10.0 -11.0 7.3 3.24 7.1 3.30 7.0 3.37 6.8 3.44 6.6 3.51
-5.0 -7.0 7.8 2.95 7.6 3.01 7.4 3.07 7.2 3.13 7.1 3.19
0.0 -2.0 8.9 2.63 8.7 2.68 8.5 2.74 8.3 2.79 8.1 2.85
5.0 3.0 9.7 2.56 9.4 2.61 9.2 2.67 9.0 2.72 8.7 2.77
7.0 6.0 9.7 2.25 9.4 2.30 9.2 2.34 9.0 2.39 8.7 2.44
10.0 8.0 9.7 2.11 9.4 2.16 9.2 2.20 9.0 2.24 8.7 2.29
15.0 10.0 9.7 1.91 9.4 1.95 9.2 1.99 9.0 2.03 8.7 2.07
20.0 15.0 9.7 1.61 9.4 1.65 9.2 1.68 9.0 1.72 8.7 1.75
24.0 18.0 9.7 1.45 9.4 1.48 9.2 1.51 9.0 1.54 8.7 1.57
33
-15.0
-16.0 6.5 3.05 6.3 3.12 6.2 3.18 6.0 3.25 5.9 3.31
-10.0 -11.0 7.3 3.24 7.1 3.30 7.0 3.37 6.8 3.44 6.6 3.51
-5.0 -7.0 7.8 2.95 7.6 3.01 7.4 3.07 7.2 3.13 7.1 3.19
0.0 -2.0 8.9 2.63 8.7 2.68 8.5 2.74 8.3 2.79 8.1 2.85
5.0 3.0 9.7 2.56 9.4 2.61 9.2 2.67 9.0 2.72 8.7 2.77
7.0 6.0 9.7 2.25 9.4 2.30 9.2 2.34 9.0 2.39 8.7 2.44
10.0 8.0 9.7 2.11 9.4 2.16 9.2 2.20 9.0 2.24 8.7 2.29
15.0 10.0 9.7 1.91 9.4 1.95 9.2 1.99 9.0 2.03 8.7 2.07
20.0 15.0 9.7 1.61 9.4 1.65 9.2 1.68 9.0 1.72 8.7 1.75
24.0 18.0 9.7 1.45 9.4 1.48 9.2 1.51 9.0 1.54 8.7 1.57
32
-15.0
-16.0 6.5 3.05 6.3 3.12 6.2 3.18 6.0 3.25 5.9 3.31
-10.0 -11.0 7.3 3.24 7.1 3.30 7.0 3.37 6.8 3.44 6.6 3.51
-5.0 -7.0 7.8 2.95 7.6 3.01 7.4 3.07 7.2 3.13 7.1 3.19
0.0 -2.0 8.9 2.63 8.7 2.68 8.5 2.74 8.3 2.79 8.1 2.85
5.0 3.0 9.7 2.56 9.4 2.61 9.2 2.67 9.0 2.72 8.7 2.77
7.0 6.0 9.7 2.25 9.4 2.30 9.2 2.34 9.0 2.39 8.7 2.44
10.0 8.0 9.7 2.11 9.4 2.16 9.2 2.20 9.0 2.24 8.7 2.29
15.0 10.0 9.7 1.91 9.4 1.95 9.2 1.99 9.0 2.03 8.7 2.07
20.0 15.0 9.7 1.61 9.4 1.65 9.2 1.68 9.0 1.72 8.7 1.75
24.0 18.0 9.7 1.45 9.4 1.48 9.2 1.51 9.0 1.54 8.7 1.57
31
-15.0
-16.0 6.5 3.05 6.3 3.12 6.2 3.18 6.0 3.25 5.9 3.31
-10.0 -11.0 7.3 3.24 7.1 3.30 7.0 3.37 6.8 3.44 6.6 3.51
-5.0 -7.0 7.8 2.95 7.6 3.01 7.4 3.07 7.2 3.13 7.1 3.19
0.0 -2.0 8.9 2.63 8.7 2.68 8.5 2.74 8.3 2.79 8.1 2.85
5.0 3.0 9.7 2.56 9.4 2.61 9.2 2.67 9.0 2.72 8.7 2.77
7.0 6.0 9.7 2.25 9.4 2.30 9.2 2.34 9.0 2.39 8.7 2.44
10.0 8.0 9.7 2.11 9.4 2.16 9.2 2.20 9.0 2.24 8.7 2.29
15.0 10.0 9.7 1.91 9.4 1.95 9.2 1.99 9.0 2.03 8.7 2.07
20.0 15.0 9.7 1.61 9.4 1.65 9.2 1.68 9.0 1.72 8.7 1.75
24.0 18.0 9.7 1.45 9.4 1.48 9.2 1.51 9.0 1.54 8.7 1.57
30
-15.0
-16.0 6.5 3.05 6.3 3.12 6.2 3.18 6.0 3.25 5.9 3.31
-10.0 -11.0 7.3 3.24 7.1 3.30 7.0 3.37 6.8 3.44 6.6 3.51
-5.0 -7.0 7.8 2.95 7.6 3.01 7.4 3.07 7.2 3.13 7.1 3.19
0.0 -2.0 8.9 2.63 8.7 2.68 8.5 2.74 8.3 2.79 8.1 2.85
5.0 3.0 9.7 2.56 9.4 2.61 9.2 2.67 9.0 2.72 8.7 2.77
7.0 6.0 9.7 2.25 9.4 2.30 9.2 2.34 9.0 2.39 8.7 2.44
10.0 8.0 9.7 2.11 9.4 2.16 9.2 2.20 9.0 2.24 8.7 2.29
15.0 10.0 9.7 1.91 9.4 1.95 9.2 1.99 9.0 2.03 8.7 2.07
20.0 15.0 9.7 1.61 9.4 1.65 9.2 1.68 9.0 1.72 8.7 1.75
24.0 18.0 9.7 1.45 9.4 1.48 9.2 1.51 9.0 1.54 8.7 1.57
28
-15.0
-16.0 6.5 3.05 6.3 3.12 6.2 3.18 6.0 3.25 5.9 3.31
-10.0 -11.0 7.3 3.24 7.1 3.30 7.0 3.37 6.8 3.44 6.6 3.51
-5.0 -7.0 7.8 2.95 7.6 3.01 7.4 3.07 7.2 3.13 7.1 3.19
0.0 -2.0 8.9 2.63 8.7 2.68 8.5 2.74 8.3 2.79 8.1 2.85
5.0 3.0 9.7 2.56 9.4 2.61 9.2 2.67 9.0 2.72 8.7 2.77
7.0 6.0 9.7 2.25 9.4 2.30 9.2 2.34 9.0 2.39 8.7 2.44
10.0 8.0 9.7 2.11 9.4 2.16 9.2 2.20 9.0 2.24 8.7 2.29
15.0 10.0 9.7 1.91 9.4 1.95 9.2 1.99 9.0 2.03 8.7 2.07
20.0 15.0 9.7 1.61 9.4 1.65 9.2 1.68 9.0 1.72 8.7 1.75
24.0 18.0 9.7 1.45 9.4 1.48 9.2 1.51 9.0 1.54 8.7 1.57
- 408 -
6-3. Heating capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
