Parts
Exterior Part name Model name Summary
Remote Sensor
Unit
UTY-XSZX
Thermo-sensor for sensing the
temperature of arbitrary place in the
room.
Auto Louver
Grille Kit
UTD-GXTA-W
Width: 683 mm
For 07, 09, 12, and 14 models
Auto Louver
Grille Kit
UTD-GXTB-W
Width: 883 mm
For 18 model
Air Cleaning
Filter
UTR-FA16-5
Air Cleaning Filter can be mounted to
the indoor unit.
External
Connect Kit
UTY-XWZX
Use to connect with various peripheral
devices and air conditioner PCB.
External
Connect Kit
UTY-XWZXZ5
Required when external device is
connected.
External
Connect Kit
UTY-XWZXZG
Use to connect with various peripheral
devices and air conditioner PCB.
For control output port.
Air Outlet
Shutter Plate
UTR-YDZB
Installed at the air outlet when 3-
directions mode is performed.
Fresh Air Intake
Kit
UTZ-VXAA
By attaching Fresh Air Intake Kit to the
indoor unit, it can be taken in fresh air
of up to 10% of “high” air volume of
the indoor unit.
Insulation
kit
Insulation Kit for
High Humidity
UTZ-KXGC
Install when the under-roof condition is
expected to be the humidity of over
80% and the temperature of over
30 °C.
Half Concealed
Kit
UTR-STA
Used for the indoor unit installing of
half concealed.
- 335 -
17-3. Others 17. Optional parts
