Fujitsu AOYG24KBTA3 Design & Technical Manual

¢
Model: ARXG18KSLAP
Unit: mm
Drain port
A
Rear view
View A
Top view
Side view
Front view Bottom view
775
174
153
72
52
295
30
49
85
952
850
P 100 × 8 = 800
49
92
78
169
56
66
10
30
150
182
193
450
850
43
33
864
900
198 168 150
78 57
- 32 -
4-2. Mini duct type 4. Dimensions
