Indoor unit connect-
ing capacity
Outdoor temperature
Indoor temperature
18.0 °CDB 21.0 °CDB 23.0 °CDB 27.0 °CDB 29.0 °CDB 32.0 °CDB
12.0 °CWB 15.0 °CWB 16.0 °CWB 19.0 °CWB 21.0 °CWB 23.0 °CWB
kBtu/h °CDB TC IP TC IP TC IP TC IP TC IP TC IP
28
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
27
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
26
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
25
-10.0
6.7 1.23 7.5 1.25 7.9 1.26 8.5 1.27 9.1 1.29 9.4 1.30
0.0 6.7 1.46 7.5 1.49 7.9 1.50 8.5 1.52 9.1 1.54 9.4 1.55
5.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
10.0 6.7 1.70 7.5 1.73 7.9 1.74 8.5 1.76 9.1 1.78 9.4 1.79
15.0 6.7 1.56 7.5 1.59 7.9 1.60 8.5 1.62 9.1 1.64 9.4 1.65
20.0 6.7 1.47 7.5 1.49 7.9 1.51 8.5 1.52 9.1 1.54 9.4 1.55
25.0 6.7 1.80 7.5 1.83 7.9 1.84 8.5 1.87 9.1 1.89 9.4 1.90
30.0 6.7 2.07 7.5 2.10 7.9 2.12 8.5 2.15 9.1 2.17 9.4 2.18
35.0 6.7 2.57 7.5 2.61 7.9 2.64 8.5 2.7 9.1 2.70 9.4 2.71
40.0 5.5 2.12 6.2 2.16 6.5 2.17 7.0 2.20 7.5 2.22 7.7 2.24
46.0 4.3 1.67 4.8 1.70 5.1 1.71 5.5 1.73 5.8 1.75 6.0 1.76
24
-10.0
6.7 1.21 7.5 1.23 7.9 1.24 8.5 1.26 9.1 1.27 9.4 1.28
0.0 6.7 1.44 7.5 1.47 7.9 1.48 8.5 1.50 9.1 1.51 9.4 1.52
5.0 6.7 1.54 7.5 1.57 7.9 1.58 8.5 1.60 9.1 1.61 9.4 1.62
10.0 6.7 1.67 7.5 1.70 7.9 1.71 8.5 1.73 9.1 1.75 9.4 1.76
15.0 6.7 1.54 7.5 1.57 7.9 1.58 8.5 1.60 9.1 1.62 9.4 1.63
20.0 6.7 1.45 7.5 1.47 7.9 1.48 8.5 1.50 9.1 1.52 9.4 1.53
25.0 6.7 1.77 7.5 1.80 7.9 1.82 8.5 1.84 9.1 1.86 9.4 1.87
30.0 6.7 2.04 7.5 2.07 7.9 2.09 8.5 2.11 9.1 2.14 9.4 2.15
35.0 6.7 2.53 7.5 2.58 7.9 2.60 8.5 2.6 9.1 2.66 9.4 2.67
40.0 5.5 2.09 6.2 2.13 6.5 2.14 7.0 2.17 7.5 2.19 7.7 2.20
46.0 5.5 1.65 6.2 1.68 6.5 1.69 7.0 1.71 7.5 1.73 7.7 1.74
23
-10.0
6.4 1.16 7.3 1.18 7.7 1.19 8.2 1.20 8.8 1.22 9.0 1.22
0.0 6.4 1.38 7.3 1.41 7.7 1.42 8.2 1.43 8.8 1.45 9.0 1.46
5.0 6.4 1.47 7.3 1.50 7.7 1.51 8.2 1.53 8.8 1.55 9.0 1.55
10.0 6.4 1.60 7.3 1.63 7.7 1.64 8.2 1.66 8.8 1.68 9.0 1.69
15.0 6.4 1.48 7.3 1.50 7.7 1.51 8.2 1.53 8.8 1.55 9.0 1.56
20.0 6.4 1.39 7.3 1.41 7.7 1.42 8.2 1.44 8.8 1.45 9.0 1.46
25.0 6.4 1.70 7.3 1.73 7.7 1.74 8.2 1.76 8.8 1.78 9.0 1.79
30.0 6.4 1.95 7.3 1.99 7.7 2.00 8.2 2.02 8.8 2.05 9.0 2.06
35.0 6.4 2.42 7.3 2.47 7.7 2.49 8.2 2.5 8.8 2.54 9.0 2.56
40.0 5.3 2.00 6.0 2.04 6.3 2.05 6.7 2.08 7.2 2.10 7.4 2.11
46.0 5.3 1.58 6.0 1.60 6.3 1.62 6.7 1.64 7.2 1.65 7.4 1.66
21
-10.0
5.9 1.04 6.6 1.06 7.0 1.07 7.5 1.08 8.0 1.09 8.3 1.10
0.0 5.9 1.24 6.6 1.26 7.0 1.27 7.5 1.29 8.0 1.30 8.3 1.31
5.0 5.9 1.32 6.6 1.35 7.0 1.36 7.5 1.37 8.0 1.39 8.3 1.39
10.0 5.9 1.44 6.6 1.46 7.0 1.47 7.5 1.49 8.0 1.51 8.3 1.51
15.0 5.9 1.32 6.6 1.35 7.0 1.36 7.5 1.37 8.0 1.39 8.3 1.40
20.0 5.9 1.24 6.6 1.27 7.0 1.28 7.5 1.29 8.0 1.30 8.3 1.31
25.0 5.9 1.52 6.6 1.55 7.0 1.56 7.5 1.58 8.0 1.60 8.3 1.61
30.0 5.9 1.75 6.6 1.78 7.0 1.80 7.5 1.82 8.0 1.84 8.3 1.85
35.0 5.9 2.18 6.6 2.21 7.0 2.23 7.5 2.26 8.0 2.28 8.3 2.29
40.0 4.8 1.79 5.5 1.83 5.7 1.84 6.2 1.86 6.6 1.88 6.8 1.89
46.0 4.8 1.41 5.5 1.44 5.7 1.45 6.2 1.47 6.6 1.48 6.8 1.49
19
-10.0
5.3 0.92 6.0 0.94 6.4 0.94 6.8 0.96 7.3 0.97 7.5 0.97
0.0 5.3 1.10 6.0 1.12 6.4 1.13 6.8 1.14 7.3 1.15 7.5 1.16
5.0 5.3 1.17 6.0 1.19 6.4 1.20 6.8 1.21 7.3 1.23 7.5 1.23
10.0 5.3 1.27 6.0 1.29 6.4 1.30 6.8 1.32 7.3 1.33 7.5 1.34
15.0 5.3 1.17 6.0 1.19 6.4 1.20 6.8 1.22 7.3 1.23 7.5 1.24
20.0 5.3 1.10 6.0 1.12 6.4 1.13 6.8 1.14 7.3 1.15 7.5 1.16
25.0 5.3 1.35 6.0 1.37 6.4 1.38 6.8 1.40 7.3 1.41 7.5 1.42
30.0 5.3 1.55 6.0 1.58 6.4 1.59 6.8 1.61 7.3 1.63 7.5 1.64
35.0 5.3 1.93 6.0 1.96 6.4 1.98 6.8 2.00 7.3 2.02 7.5 2.03
40.0 4.4 1.59 4.9 1.62 5.2 1.63 5.6 1.65 6.0 1.67 6.2 1.68
46.0 4.4 1.25 4.9 1.27 5.2 1.29 5.6 1.30 6.0 1.31 6.2 1.32
- 371 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
