Floor type
Model: AGYG09KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
-5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
0.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
15.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
20.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
25.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
30.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
35.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
40.0 2.23 1.36 2.52 1.55 2.66 1.78 2.85 2.00 3.04 2.19 3.14 2.51
46.0 1.93 1.02 2.18 1.16 2.30 1.33 2.46 1.50 2.63 1.64 2.72 1.88
Model: AGYG12KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
-5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
0.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
15.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
20.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
25.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
30.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
35.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
40.0 3.00 1.71 3.39 1.95 3.57 2.24 3.83 2.52 4.09 2.76 4.22 3.16
46.0 2.60 1.28 2.93 1.46 3.09 1.68 3.31 1.89 3.54 2.06 3.65 2.36
Model: AGYG14KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
-5.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
0.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
5.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
10.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
15.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
20.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
25.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
30.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
35.0 3.66 2.28 4.14 2.60 4.36 2.99 4.67 3.36 4.99 3.68 5.15 4.21
40.0 3.26 1.81 3.68 2.06 3.88 2.37 4.16 2.66 4.44 2.91 4.58 3.34
46.0 2.82 1.35 3.19 1.54 3.36 1.77 3.60 1.99 3.84 2.18 3.96 2.50
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 369 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
