Fujitsu AOYG24KBTA3 Design & Technical Manual

Model: ASYG07KETF, ASYG07KETF-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
-5.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
0.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
5.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
10.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
15.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
20.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
25.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
30.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
35.0 1.96 1.10 2.22 1.26 2.34 1.45 2.50 1.63 2.67 1.78 2.76 2.04
40.0 1.74 0.87 1.97 1.00 2.08 1.15 2.23 1.29 2.38 1.41 2.45 1.61
46.0 1.51 0.65 1.71 0.74 1.80 0.86 1.93 0.96 2.06 1.05 2.12 1.21
Model: ASYG09KETF, ASYG09KETF-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
-5.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
0.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
5.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
10.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
15.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
20.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
25.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
30.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
35.0 2.51 1.41 2.84 1.61 2.99 1.85 3.20 2.08 3.42 2.27 3.53 2.61
40.0 2.23 1.12 2.52 1.27 2.66 1.47 2.85 1.65 3.04 1.80 3.14 2.06
46.0 1.93 0.84 2.18 0.95 2.30 1.10 2.46 1.23 2.63 1.35 2.72 1.55
Model: ASYG12KETF, ASYG12KETF-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
-5.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
0.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
5.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
10.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
15.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
20.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
25.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
30.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
35.0 3.37 1.90 3.81 2.16 4.02 2.49 4.30 2.80 4.60 3.06 4.74 3.50
40.0 3.00 1.50 3.39 1.71 3.57 1.97 3.83 2.21 4.09 2.42 4.22 2.77
46.0 2.60 1.12 2.93 1.28 3.09 1.47 3.31 1.66 3.54 1.81 3.65 2.08
Model: ASYG14KETF, ASYG14KETF-B
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
-5.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
0.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
5.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
10.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
15.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
20.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
25.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
30.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
35.0 3.66 2.06 4.14 2.35 4.36 2.70 4.67 3.04 4.99 3.32 5.15 3.80
40.0 3.26 1.63 3.68 1.86 3.88 2.14 4.16 2.40 4.44 2.63 4.58 3.01
46.0 2.82 1.22 3.19 1.39 3.36 1.60 3.60 1.80 3.84 1.97 3.96 2.26
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 368 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
