Fujitsu AOYG24KBTA3 Design & Technical Manual


Floor type
Model: AGYG09KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
-5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
0.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
5.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
10.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
15.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
20.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
25.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
30.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
35.0 2.51 1.71 2.84 1.95 2.99 2.25 3.20 2.53 3.42 2.76 3.53 3.17
40.0 2.06 1.15 2.32 1.31 2.45 1.51 2.62 1.70 2.81 1.86 2.89 2.13
46.0 1.61 0.70 1.81 0.80 1.91 0.92 2.05 1.04 2.19 1.13 2.26 1.30
Model: AGYG12KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
-5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
0.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
5.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
10.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
15.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
20.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
25.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
30.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
35.0 3.37 2.16 3.81 2.46 4.02 2.83 4.30 3.18 4.60 3.48 4.74 3.99
40.0 2.76 1.45 3.12 1.65 3.29 1.90 3.53 2.14 3.77 2.34 3.89 2.68
46.0 2.16 0.88 2.44 1.01 2.57 1.16 2.75 1.30 2.94 1.43 3.03 1.63
Model: AGYG14KVCA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
-5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
0.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
15.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
20.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
25.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
30.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
35.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
40.0 3.21 1.64 3.63 1.87 3.83 2.15 4.10 2.42 4.38 2.65 4.52 3.03
46.0 2.51 1.00 2.84 1.14 2.99 1.31 3.20 1.47 3.42 1.61 3.53 1.85
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 391 -
6-2. Cooling capacity 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
