Heating
Combination of indoor unit
Rated capacity for each in-
door unit (kBtu/h)
Total capacity
(kBtu/h)
Input power (kW)
COP
(W/W)
Seasonal data
Room
Total
Room
Min. Rated Max. Min. Rated Max.
Pdesign
(kW)
SCOP
(kWh/kWh)
Energy effi-
ciency class
1 3 2 1 2 3
7 7 — 14 2.40 2.40 — 2.0 4.80 5.6 0.25 1.00 1.30 4.80 4.0 4.2 A+
7 9 — 16 2.40 3.00 — 2.0 5.40 6.4 0.25 1.21 1.48 4.45 4.0 4.2 A+
7 12 — 19 2.40 4.20 — 2.0 6.60 7.6 0.25 1.66 1.76 3.98 5.0 4.0 A+
7 14 — 21 2.27 4.53 — 2.0 6.80 8.0 0.25 1.77 1.85 3.84 5.0 4.0 A+
9 9 — 18 3.00 3.00 — 2.0 6.00 7.2 0.25 1.44 1.67 4.17 4.5 4.1 A+
9 12 — 21 2.91 3.89 — 2.0 6.80 8.0 0.25 1.77 1.85 3.84 5.0 4.0 A+
9 14 — 23 2.66 4.14 — 2.0 6.80 8.0 0.25 1.77 1.85 3.84 5.0 4.0 A+
12 12 — 24 3.40 3.40 — 2.0 6.80 8.0 0.25 1.77 1.85 3.84 5.0 4.0 A+
12 14 — 26 3.14 3.66 — 2.0 6.80 8.0 0.25 1.77 1.85 3.84 5.0 4.0 A+
14 14 — 28 3.40 3.40 — 2.0 6.80 8.0 0.25 1.77 1.85 3.84 5.0 4.0 A+
7 7 7 21 2.27 2.27 2.27 2.0 6.80 8.0 0.25 1.39 1.85 4.89 5.0 4.7 A++
7 7 9 23 2.07 2.07 2.66 2.0 6.80 8.0 0.25 1.39 1.85 4.89 5.0 4.7 A++
7 7 12 26 1.83 1.83 3.14 2.0 6.80 8.0 0.25 1.39 1.85 4.89 5.0 4.7 A++
7 7 14 28 1.70 1.70 3.40 2.0 6.80 8.0 0.25 1.39 1.85 4.89 5.0 4.7 A++
7 9 9 25 1.90 2.45 2.45 2.0 6.80 8.0 0.25 1.39 1.85 4.89 5.0 4.7 A++
7 9 12 28 1.70 2.19 2.91 2.0 6.80 8.0 0.25 1.39 1.85 4.89 5.0 4.7 A++
7 9 14 30 1.59 2.04 3.17 2.0 6.80 8.0 0.25 1.39 1.85 4.89 5.0 4.7 A++
9 9 9 27 2.27 2.27 2.27 2.0 6.80 8.0 0.25 1.39 1.85 4.89 5.0 4.7 A++
9 9 12 30 2.04 2.04 2.72 2.0 6.80 8.0 0.25 1.39 1.85 4.89 5.0 4.7 A++
NOTES:
• 7: 7,000 Btu/h, 9: 9,000 Btu/h, 12: 12,000 Btu/h, 14: 14,000 Btu/h
• The above is the value for connecting with wall-mounted type indoor unit.
• 2 or more indoor units should be connected.
• Heating: Indoor temperature of 20 °CDB, and outdoor temperature of 7 °CDB/6 °CWB.
• Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• The total ability of connected indoor unit is from 14,000 Btu/h up to 30,000 Btu/h.
- 351 -
6-1. Combinations 6. Capacity table
OUTDOOR UNIT AOYG18-24KBTA3 OUTDOOR UNIT AOYG18-24KBTA3
