Mini duct type
Model: ARXG07KSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 1.97 1.92 1.88 1.83 1.78
-10.0 -11.0 2.23 2.18 2.13 2.07 2.02
-5.0 -7.0 2.38 2.32 2.27 2.21 2.15
0.0 -2.0 2.70 2.64 2.58 2.51 2.45
5.0 3.0 2.94 2.87 2.80 2.73 2.66
7.0 6.0 2.94 2.87 2.80 2.73 2.66
10.0 8.0 2.94 2.87 2.80 2.73 2.66
15.0 10.0 2.94 2.87 2.80 2.73 2.66
20.0 15.0 2.94 2.87 2.80 2.73 2.66
24.0 18.0 2.94 2.87 2.80 2.73 2.66
Model: ARXG09KSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 2.53 2.47 2.41 2.35 2.29
-10.0 -11.0 2.87 2.80 2.74 2.67 2.60
-5.0 -7.0 3.06 2.99 2.92 2.84 2.77
0.0 -2.0 3.48 3.39 3.31 3.23 3.15
5.0 3.0 3.78 3.69 3.60 3.51 3.42
7.0 6.0 3.78 3.69 3.60 3.51 3.42
10.0 8.0 3.78 3.69 3.60 3.51 3.42
15.0 10.0 3.78 3.69 3.60 3.51 3.42
20.0 15.0 3.78 3.69 3.60 3.51 3.42
24.0 18.0 3.78 3.69 3.60 3.51 3.42
Model: ARXG12KSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.38 3.30 3.22 3.14 3.06
-10.0 -11.0 3.83 3.74 3.65 3.56 3.47
-5.0 -7.0 4.08 3.99 3.89 3.79 3.69
0.0 -2.0 4.64 4.53 4.42 4.31 4.20
5.0 3.0 5.04 4.92 4.80 4.68 4.56
7.0 6.0 5.04 4.92 4.80 4.68 4.56
10.0 8.0 5.04 4.92 4.80 4.68 4.56
15.0 10.0 5.04 4.92 4.80 4.68 4.56
20.0 15.0 5.04 4.92 4.80 4.68 4.56
24.0 18.0 5.04 4.92 4.80 4.68 4.56
Model: ARXG14KSLAP
Outdoor temperature
Indoor temperature (°CDB)
16.0 18.0 20.0 22.0 24.0
(°CDB) (°CWB) TC TC TC TC TC
-15.0 -16.0 3.94 3.85 3.75 3.66 3.56
-10.0 -11.0 4.47 4.36 4.26 4.15 4.04
-5.0 -7.0 4.76 4.65 4.54 4.42 4.31
0.0 -2.0 5.41 5.28 5.15 5.02 4.89
5.0 3.0 5.88 5.74 5.60 5.46 5.32
7.0 6.0 5.88 5.74 5.60 5.46 5.32
10.0 8.0 5.88 5.74 5.60 5.46 5.32
15.0 10.0 5.88 5.74 5.60 5.46 5.32
20.0 15.0 5.88 5.74 5.60 5.46 5.32
24.0 18.0 5.88 5.74 5.60 5.46 5.32
