Fujitsu ARTH30KMTAP - Page 12

Unit: mm
• Distance between the ceiling and the unit is from 20 to 300:
Choose one of these methods to set up the maintenance access.
850
1,500
Pattern A
Pattern B
50
Maintenance access
450100 to 200
1,400
450 125 5050700
Air
Air
Air
Air
Control box
2,000 or more
850
50
1,400
Control box
Bottom view
- 8 -
2-3. Maintenance space requirement
2. Dimensions
DUCT TYPE ARTH30-54KMTAP DUCT TYPE ARTH30-54KMTAP
