Fujitsu ARTH30KMTAP User Manual

1. Specifications
Type Inverter heat pump
Model name ARTH30KMTAP ARTH36KMTAP
Power supply 220―240 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 8.5 10.0
Btu/h 29,000 34,100
Min.—Max.
kW 2.8—10.3 2.8—11.4
Btu/h 9,600—35,100 9,600—38,900
Heating
Rated
kW 10.0 11.2
Btu/h 34,100 38,200
Min.—Max.
kW 2.7—11.3 2.7—14.0
Btu/h 9,200—38,600 9,200—47,800
Input power
Cooling
Rated
kW
2.60 3.23
Max. 4.28 4.30
Heating
Rated 2.65 3.30
Max. 4.44 4.50
Fan
HIGH
W
168 192
MED 93 107
LOW 67 75
QUIET 50 57
Current
Cooling
Rated A
11.0 13.6
Heating 11.2 13.9
EER Cooling
kW/kW
3.27 3.10
COP Heating 3.77 3.39
TCSPF
(Calculation method: Commer-
cial)
Hot climate
kWh/kWh
4.78 4.64
Average climate 4.91 4.78
Cool climate 5.26 5.14
HSPF
(Calculation method: Commer-
cial)
Hot climate
kWh/kWh
4.31 4.23
Average climate 4.28 4.07
Cool climate 3.80 3.44
Power factor
Cooling
%
98.5 99.0
Heating 98.6 98.9
Moisture removal L/h (pints/h) 1.6 (2.8) 2.9 (5.1)
Maximum operating current *
1
Cooling
A
22.6
Heating 22.6
Fan
Airflow rate
Cooling
HIGH
m
3
/h
1,950 2,070
MED 1,540 1,660
LOW 1,340 1,450
QUIET 1,210 1,280
Heating
HIGH 1,950 2,070
MED 1,540 1,660
LOW 1,340 1,450
QUIET 1,210 1,280
Type × Q'ty Sirocco fan × 3
Motor output W 275
Static pressure range Pa 50 to 150
Sound pressure level *
2
Cooling
HIGH
dB (A)
38
MED 34
LOW 31
QUIET 28
Heating
HIGH 38
MED 34
LOW 31
QUIET 28
Sound power level dB (A) 63 64
Heat exchanger type
Dimensions (H × W × D)
mm
336 × 1,190 × 39.9
Fin pitch 1.4
Rows × Stages 3 × 16
Pipe type Copper
Fin type Aluminum
Enclosure
Material Steel sheet
Color ―
Dimensions
(H × W × D)
Net
mm
240 × 1,400 × 700
Gross 334 × 1,626 × 863
Weight
Net
kg
42
Gross 48
Connection pipe
Size
Liquid
mm (in)
Ø9.52 (Ø3/8)
Gas Ø15.88 (Ø5/8)
Method Flare
Drain port
Material PVC
Tip diameter mm Ø26 (I.D.), Ø32 (O.D.)
Drain hose
Material PVC
Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wired remote controller (Option: Simple remote controller, IR receiver unit)
International protection rating IPX0
- 2 -
1. Specifications
