Fujitsu ARTH30KMTAP - Outdoor Unit Electrical Characteristics

10. Electrical characteristics
Model name AOTH30KBTA AOTH36KBTA
Power supply
Voltage V 220―240 ~
Frequency Hz 50
Max operating current *
1
A 22.6 22.6
Starting current A 11.2 13.9
Wiring spec.
*
2
Circuit breaker current A 25
Power cable
mm
2
4.0
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 51
Model name AOTH45KBTA AOTH54KBTA
Power supply
Voltage V 220―240 ~
Frequency Hz 50
Max operating current *
1
A 28.5 28.5
Starting current A 16.8 18.7
Wiring spec.
*
2
Circuit breaker current A 32
Power cable
mm
2
4.0
Connection
cable *3
Cross-sectional area
mm
2
1.5
Limited wiring length m 51
*
1
: Maximum operating current is the total current of the indoor unit and the outdoor unit.
*
2
: Selected sample based on Japan Electrotechnical Standards and Codes Committee E0005. As
the regulations of wire size and circuit breaker differ in each country or region, select appropriate de-
vices complied to the regional standard.
*
3
: Limit voltage drop to less than 2%. If voltage drop is 2% or more, increase cable conductor size.
- 80 -
10. Electrical characteristics
OUTDOOR UNIT AOTH30-54KBTA OUTDOOR UNIT AOTH30-54KBTA
