9-2. Sound level check point
1 m
1.5 m
Airflow
MicrophoneMicrophone
Front
Front viewSide view
NOTE: Detailed shape of the actual outdoor unit might be slightly different from the one illustrated
above.
- 79 -
9-2. Sound level check point
9. Operation noise (sound pressure)
OUTDOOR UNIT AOTH30-54KBTA OUTDOOR UNIT AOTH30-54KBTA
