Models: ARTH45KMTAP and ARTH54KMTAP
Airflow
Fan performance curve 1
External static pressure (Pa)
0
50
100
150
200
(m
3
/h)
(l/s)
1,000
278
1,500
417
2,000
556
2,500
695
Hi (SP mode 15)
SP mode 15
upper limit
Me (SP mode 15)
Lo (SP mode 15)
Qu (SP mode 15)
Standard SP upper limit
Standard SP lower limit
Hi (Standard SP)
Me (Standard SP)
Lo (Standard SP)
Qu (Standard SP)
Fan performance curve 2
(For function setting by remote controller)
Airflow
External static pressure (Pa)
0
50
100
150
200
(m
3
/h)
(l/s)
1,000
278
1,500
417
2,000
556
2,500
695
Hi (SP mode 15)
Hi (SP mode 14)
Hi (SP mode 13)
Hi (SP mode 12)
Hi (SP mode 11)
Hi (SP mode 10)
Hi (SP mode 09)
Hi (SP mode 08)
Hi (SP mode 07)
Hi (SP mode 06)
Hi (SP mode 05
or Standard SP)
Me
Lo
Qu
NOTES:
Setting of the external static pressure is switchable into modes by using the remote controller.
According to the resistance of the connecting duct, perform the setting of the external static
pressure with referring “Fan performance curve 2” above.
The default setting is set at “Standard SP”.
- 18 -
5-1. Fan performance curve
5. Fan performance
DUCT TYPE
ARTH30-54KMTAP
DUCT TYPE
ARTH30-54KMTAP
