 Characteristics of air volume and capacity
• Cooling
1,700 1,800 1,900 2,000 2,100 2,200 2,300 2,400 2,500 2,600 2,700
Capacity (%)
95
96
97
98
99
100
101
102
103
104
105
Airflow
472 500 528 556 583 611 639 667 695 722 750
(m
3
/h)
(l/h)
• Heating
1,700 1,800 1,900 2,000 2,100 2,200 2,300 2,400 2,500 2,600 2,700
Capacity (%)
95
96
97
98
99
100
101
102
103
104
105
Airflow
472 500 528 556 583 611 639 667 695 722 750
(m
3
/h)
(l/h)
- 19 -
5-1. Fan performance curve
5. Fan performance
DUCT TYPE ARTH30-54KMTAP DUCT TYPE ARTH30-54KMTAP
