Fujitsu ARTH30KMTAP User Manual

Type Inverter heat pump
Model name ARTH45KMTAP ARTH54KMTAP
Power supply 220―240 V ~ 50 Hz
Power supply intake Outdoor unit
Available voltage range 198—264 V
Capacity
Cooling
Rated
kW 12.5 13.0
Btu/h 42,700 44,400
Min.—Max.
kW 4.0—14.0 4.5—15.0
Btu/h 13,600—47,800 15,400—51,200
Heating
Rated
kW 14.0 15.0
Btu/h 47,800 51,200
Min.—Max.
kW 4.2—16.5 4.7—18.0
Btu/h 14,300—56,300 16,000—61,400
Input power
Cooling
Rated
kW
4.00 4.31
Max. 5.18 5.19
Heating
Rated 4.00 4.45
Max. 5.22 5.23
Fan
HIGH
W
211
MED 119
LOW 81
QUIET 60
Current
Cooling
Rated A
16.8 18.1
Heating 16.8 18.7
EER Cooling
kW/kW
3.13 3.02
COP Heating 3.50 3.37
TCSPF
(Calculation method: Commer-
cial)
Hot climate
kWh/kWh
4.78 4.66
Average climate 4.94 4.84
Cool climate 5.33 5.22
HSPF
(Calculation method: Commer-
cial)
Hot climate
kWh/kWh
4.24 4.13
Average climate 4.08 3.93
Cool climate 3.62 3.34
Power factor
Cooling
%
99.2 99.2
Heating 99.2 99.2
Moisture removal L/h (pints/h) 4.5 (7.9) 5.0 (8.8)
Maximum operating current *
1
Cooling
A
28.5
Heating 28.5
Fan
Airflow rate
Cooling
HIGH
m
3
/h
2,160
MED 1,730
LOW 1,510
QUIET 1,320
Heating
HIGH 2,160
MED 1,730
LOW 1,510
QUIET 1,320
Type × Q'ty Sirocco fan × 3
Motor output W 275
Static pressure range Pa 50 to 150
Sound pressure level *
2
Cooling
HIGH
dB (A)
40
MED 36
LOW 32
QUIET 29
Heating
HIGH 40
MED 36
LOW 32
QUIET 29
Sound power level dB (A) 65
Heat exchanger type
Dimensions (H × W × D)
mm
336 × 1,190 × 39.9
Fin pitch 1.4
Rows × Stages 3 × 16
Pipe type Copper
Fin type Aluminum
Enclosure
Material Steel sheet
Color ―
Dimensions
(H × W × D)
Net
mm
240 × 1,400 × 700
Gross 334 × 1,626 × 863
Weight
Net
kg
42
Gross 48
Connection pipe
Size
Liquid
mm (in)
Ø9.52 (Ø3/8)
Gas Ø15.88 (Ø5/8)
Method Flare
Drain port
Material PVC
Tip diameter mm Ø26 (I.D.), Ø32 (O.D.)
Drain hose
Material PVC
Tip diameter mm Ø25 (I.D.), Ø32 (O.D.)
Operation range
Cooling
°C 18 to 32
%RH 80 or less
Heating °C 16 to 30
Remote controller type Wired remote controller (Option: Simple remote controller, IR receiver unit)
International protection rating IPX0
NOTES:
• Specifications are based on the following conditions:
– Cooling: Indoor temperature of 27 °CDB/19°CWB, and outdoor temperature of 35 °CDB/24°CWB.
– Heating: Indoor temperature of 20 °CDB/15°CWB, and outdoor temperature of 7 °CDB/6.
– Pipe length: 7.5m, Height difference: 0m. (Between outdoor unit and indoor unit.), Standard static pressure; 50 Pa
• Protective function might work when using it outside the operation range.
• *
1
: Maximum current:
– The maximum value when operated within the operation range.
– The total current of indoor unit and outdoor unit.
• *
2
: Sound pressure level:
– Measured values in manufacturer’s anechoic chamber.
– Because of the surrounding sound environment, the sound levels measured in actual installation conditions might be higher than the specified values here.
- 4 -
1. Specifications
DUCT TYPE ARTH30-54KMTAP DUCT TYPE ARTH30-54KMTAP

Fujitsu ARTH30KMTAP Specifications

General

Brand	Fujitsu
Model	ARTH30KMTAP
Category	Air Conditioner
Language	English
