Technical specificati on
Video/TV operating modes via digital video inputs
Screen resolutio n Refresh rate Aspect ratio
640 x 480 p 60 Hz 4:3
720 x 576 p 50 Hz
4:3 / 16:9
1280 x 720 p
50 / 60 Hz 4:3 / 16:9
1920 x 1080 p
50 / 60 Hz 4:3 / 16:9
SUBDport
610
1115
51
Pin Meaning
1 Video input red
2 Video input green
3 Video input blue
4
Ground
5
Ground
6 Video groun
dred
7
Video grou
nd green
8 Video gro
und blue
9
+5 V (DDC)
10
Sync. ground
11
Groun
d
12
DDC Data
13 H. sync
14 V. sync
15
DDC Clock
